2.1. SETTING UP RT GTC WALL MOUNT

► 1 – Open the box
► Pull the 2 buttons on the 2 sides of the product.
► Remove the lid.
► Choice of output for the cables: the rear - 1
► 2 – Attach the box to the wall using 2 x 5mm dia. screws (not supplied).
► 3 – Connect the power terminals to the grid (see chapter 2.2. Connection).
► 4 – Close the box.
5 – Perform programming by using the six buttons located beside the LCD screen.
►
19
3
MDE-Radio-Timing-GTC-3080V2.3
2. SETTING
the chute by up or down - 2 and 3
367
330
19
2
2
1
1
UP AND CONNECTING
367
330
DIN option
2
3
