deVice deScription

On/Off Switches the device on.
If „On/Off" is pressed during use,
the following options are available:
Keylock Activates or disables the display lock
Screen Switches off the display to save power.
However, ongoing navigations and
track recordings remain active.
Stand-By
Switches to stand-by mode.
Switch off Switches the device off completely.
Control key Rapid access to Settings for changing
the volume and brightness -
save battery.
note: Rapid access can be assigned other settings. To do this,
select System/General > Hardware button assignment on the
Settings menu and select the function you want.
22
Control key
Screen/Display
USB-port On/Off
Opening the battery compartment:
microSD-card
Control key
battery
compartment
Fitting to bicYcle - procedure
1. Place bracket onto the handlebar or stem.
2. Cable ties
Bracket
Release lever
3. Screws
iMportant: The cable ties must rest against the handlebar without any gaps so that
the bracket does not shift even when riding on rough roads or farm tracks. For stabilisati-
on, the bracket is equipped with a „tyre" profile on the inside to prevent it from slipping.
tip: We recommend for the best stability on the bicycle that the
bracket be attached to the stem!
Slide the device into the bracket from the front and make sure
Mounting
that it is inserted correctly into the guide rails at the side of
Cable ties
the bracket. The device can be heard to lock in place in the
bracket. To release the device from the bracket, press the
release lever down and slide the device out of the bracket.
Pull cable ties through the slots provided for them. When
doing so, make sure that the cable ties are pulled tight so that
they are taut around the handlebar/stem.
Guide screws for fitting through the clamp shell and connect
them to the bracket. For this purpose, the clamp shell can be
attached in accordance with the attachment to the handlebar
or stem rotated by 90 degrees. Secure the clamp shell with
the release lever counter to the direction of travel.
