ENGLISH
SETTING GOBO ROTATION
• Select the fixtures you want to control
• Press ROTATION button
• Select a rotation speed value with 1~12 buttons, or move the X-
Fade/Value slider
Below is the Gobo Rotation settings: ( CCW- Counterclockwise; CW- Clockwise )
1 2 3 4 5
Fast CCW. CCW. CCW.
Rotation Stop CCW Speed Speed Speed
Speed 1 2 3
SETTING DIMMER
• Select the fixtures you want to control
• Press DIMMER button
• Select a dimmer value with 1~12 buttons, or move the X-Fade/Value
slider
• You can adjust dimmer value of fixtures between 0%~100%
The Dimmer settings are as below:
1 2 3 4 5
Dimmer 100% 90% 82% 74% 64%
SETTING FOCUS
• Select the fixtures you want to control
• Press FOCUS button
• Select a focus value with 1~12 buttons, or move the X-Fade/Value
slider
• To select focus 13~24, press FOCUS again to next page, the lower
LED will be on.
CREATE A SCENE
1. Enter Program mode.
2. a) Press Scanners button to choose the fixtures you want to
control
b) Use Joystick or sliders to locate the positions of pan/tilt to
create a scene.
3. Press SAVE. The 1~12 buttons will light up if they have memory
already saved into them.
4. Press a button to store your desired scene.
5. The scene is saved into the selected button.
JB SYSTEMS
OPERATION MANUAL
6 7 8 9 10 11
Slow Slow CW. CW. CW. Fast
CCW. CW. Speed Speed Speed CW.
Speed Speed 3 2 1 Speed
6 7 8 9 10 11
55% 46% 37% 28% 19% 10%
9/57 iLEAD Controller
ENGLISH
CREATE A CHASE
12
Stop
RUNNING SCENES
12
0%
Note:
The SAVE button is used to store the current status into memory.
The PAGE button is used to select the position of memory. The controller has 24
position in which you can save chases ( shows ) into them. When the upper LED is on,
then button 1 = memory 1, button 2 = memory 2... etc, when the lower LED is on then
button 1 = memory 13, button 2 = memory 14... etc.
The MEMORY button is used to read exiting scenes. The LEDs will light up if there is
memory saved into the buttons.
INSERT A SCENE
JB SYSTEMS
6. By pressing Page, you can also store scenes into 13~24 button.
1. Enter Program mode.
2. Create a scene.
3. Press SAVE button. Select a position ( 1 ~ 24 ) where you want to
store the scene.
4. Repeat steps 2 & 3 as many times as you want until the controller's
memory is full. The SAVE LED will blink when the memory is full.
5. A chase (The controller ) can store up to 485 scenes.
1. Enter Program mode.
2. Press MEMORY button.
3. Press a button 1~12 or press PAGE select button 13~24 for
manually running a scene.
4. Press the same button again. The second scene will be run after
the first scene.
1. Enter Program mode.
2. Press the MEMORY button, choose the desired position (1 ~ 24)
in which you want to insert a scene.
3. Select the scene where you want to insert a scene. Press the
same button ( e.g. 6 ) repeatedly, you can view the scene one by
one.
4. Create a new scene.
5. Press SAVE.
10/57
OPERATION MANUAL
iLEAD Controller
