ENGLISH
REMOTELY SET DMX ADDRESS
• Hold on the BLACKOUT/STAND ALONE button for 3 seconds to
enter Stand-Alone mode.
• Hold down the SCANNERS button and then press BLACKOUT/
STAND ALONE button. You will see the pan & tilt of all the fixtures
in the chain stopping at the central position. The shutter & LED of
the first fixture will open/ blink indicating the fixture is active, ready
to be designated a new position ( the number in the chain ).
• If you have two chains in the venue, you can jog ( push ) joystick
Left/Right to select chain 1 or chain 2, and jog joystick Up / Down
to select next fixture or last fixture.
• Select 1~12 button to set DMX address.
• Press SCANNERS to next page to select 13~24 button for setting
DMX address.
• Press the BLACKOUT/STAND ALONE button again to return to
the program mode.
Fixtures No.
1
2
3
4
DMX channel for
1
9
17
25
Moving Head
Scanner
Barrel
Color changer
3
11
19
27
Multi-Gobo projector
Fixtures No.
13
14
15
16
DMX channel for
97
105
113
121
Moving Head
Scanner
Barrel
Color changer
99
107
115
123
Multi-gobo projector
JB SYSTEMS
OPERATION MANUAL
5
6
7
8
9
10
11
33
41
49
57
65
73
81
35
43
51
59
67
75
83
17
18
19
20
21
22
23
129
137
145
155
161
169
177
131
139
147
157
163
171
179
5/57
iLEAD Controller
ENGLISH
SELECT THE FIXTURES YOU WANT TO CONTROL
Upper
1
Lower
13
You will see the button's LED turned on when you select it. When the LEDs above the
buttons are lit, you can control the fixtures using joystick or control sliders. To exit
control of a fixture, press the number buttons again so the buttons LED light goes out.
You can control multiple fixtures at same time. To select multiple fixtures, press the
button of each fixture one by one.
SETTING PAN/TILT POSITION
Move joystick Left/Right to control the Pan movement, Up/Down to control the Tilt
movement. You can also use the Speed slider and X-Fade/Value slider to control Pan
or Tilt movement of the fixture.
SETTING MOVEMENT
12
89
91
When programming, you can select a movement pattern to create a scene. Use the
Speed slider to set pan movement range, and use the X-Fade/Value slider setting tilt
24
movement range. On the other hand, use Joystick to set the position of movement.
185
When in Light show mode, you can use the Speed slider to set running time within the
range of 0.1 second to 5 minutes, and use X-Fade /Value slider to set fade time.
187
JB SYSTEMS
• Press SCANNERS button
• You can choose one or more than one fixtures by pressing the
1~12 buttons
• When the buttons' LED ( 1 ~ 12 ) are lit, you can control the
fixtures.
• To select fixture 13~24, press SCANNERS to next page, the lower
LED will be on.
2
3
4
5
6
7
8
14
15
16
17
18
19
20
• Select the fixtures you want to control
• Press MOVEMENT button
• Select preset Movement patterns by pressing 1~12 buttons, and
use the X-Fade/Value slider to adjust movement range
• Press MOVEMENT again to return to Program mode
• 12 preset Movement patterns are as below:
1
2
3
4
5
6
Movement
6/57
OPERATION MANUAL
9
10
11
12
21
22
23
24
7
8
9
10
11
12
iLEAD Controller
