HOW TO ATTACH THE SEAT TO THE FRAME

LOCKING
FROM BEHIND
LEVER
LOCKS
FIG. B
VIEW
S A F E T Y R E
PUSH-BUTTON
UNLOCKS
AFTER APPLYING BRAKES, PLACE
THE SEAT ON THE MOUNTING PLATE (Fig. A)
FIG. A
VIEW FROM ABOVE THE FRAME
PUSH THE SEAT BACKWARDS SLIDING IT
ON TO THE MOUNTING PLATE
OPERATE THE LOCKING LEVER. (AS IN
FIG. B) THE CLICK OF THE SAFETY RED PUSH-
BUTTON MEANS THAT IS WELL LOCKED
D
34/92
MOUNTING
PLATE
MAKE SURE THE SEAT IS
IN THE MOUNTING PLATE
BEFORE LOCKING IT WITH
THE LEVER
