SEATING UNIT ADJUSTMENTS ON BASES 869, 901 AND 856

ADJUSTING THE INCLINATION OF THE SEAT (TILT-IN-SPACE SYSTEM)

1.
PULL UP THE RED KNOB
2.
TILT THE SEAT KEEPING THE KNOB PULLED AND RELEASE IT WHEN ADJUSTED TO
THE DESIRED POSITION
VIEW FROM BEHIND
23/9
RED KNOB
FOR ADJUSTING THE INCLINATION
OF THE SEAT
