Peel off the back of the self-stick mounting label template included with the unit and place at the desired mounting position. If you do not have the self-stick mounting template label, refer to the Mounting Diagrams in this Bosch Sicherheitssyteme GmbH | V 1.2 | 2009.09...
Trim and cover all conductors that are not used. The table below shows how you should wire the reader to the controller. Color Wiegand Output DC + Input Black Ground White Data 1 Green Data 0 | V 1.2 | 2009.09 Bosch Sicherheitssyteme GmbH...
Seite 7
After the card data is processed by the controller, the controller can then turn the LED green. Refer to the controller description of the LED operation if the reader LED is controlled by the controller. Bosch Sicherheitssyteme GmbH | V 1.2 | 2009.09...
Seite 8
Height x Widht X Depth 4.72 x 1.65 x 0.55 inch (119.95 x 41.95 x 14 mm) * Measured using Bosch Proximity Card (P/N ACD-ATR11ISO) or equivalent. Range also depends on electrical environment and/ or proximity to metal. Suitable for Outdoor Use | V 1.2 | 2009.09...
ARD-AYH12 Installation Manual | en MOUNTING DIAGRAM Bosch Sicherheitssyteme GmbH | V 1.2 | 2009.09...
Seite 10
| Installation Manual ARD-AYH12 | V 1.2 | 2009.09 Bosch Sicherheitssyteme GmbH...
Seite 11
ARD-AYH12 Installationshandbuch | de Installationshandbuch Der ARD-AYH12 ist ein RFID-Leser für berührungslose Ausweise und kann in Zutrittskontrollsysteme installiert werden. Dieses Installationshandbuch enthält folgende Informationen: Montageanleitung Verkabelungsanleitung Bedienungsanleitung Technische Daten MONTAGEANLEITUNG 1 = Um die obere Abdeckung zu entfernen, muss die an der Unterseite des Lesers befindliche Schraube der oberen Abdeckung abgeschraubt werden.
Zutrittskontrollgerät verwendet werden, dessen Netzteil CE- zugelassen ist bzw. das mit einem gleichwertigen Netzteil ausgestattet ist. VERKABELUNGSANLEITUNG Der ARD-AYH12 wird mit einem 45 cm langen 6-adrigen Anschlusskabel geliefert. Gehen Sie zum Anschließen des Lesers an den Kontroller wie folgt vor: Bereiten Sie das Leser-Kabel vor, indem Sie den Kabelmantel auf einer Länge von...
Seite 13
Nachdem die Kartendaten vom Kontroller verarbeitet worden sind, wird die LED vom Kontroller auf grün geschaltet. Wenn die LED des Lesers vom Kontroller gesteuert wird, finden Sie entsprechende Hinweise in der Kontroller-Beschreibung für den LED-Betrieb. Bosch Sicherheitssyteme GmbH | V 1.2 | 2009.09...
Seite 14
Betriebs Abmessungen Höhe x Breite x Tiefe 109,91 x 74,91 x 15 mm * Gemessen mit Bosch berührungslosem Ausweis (Artikelnr. ACD-ATR11ISO) oder einer gleichwertigen Komponente. Die Reichweite hängt auch von der elektrischen Umgebung und/ oder der Nähe zu Metall ab.
Seite 19
ARD-AYH12 安装手册 | zh 操作说明 读卡器在连接到电源和控制器后应进行测试。 为此,请执行以下步骤: 打开读卡器电源。 LED 指示灯和蜂鸣器将激活三次。 这表示读卡 器正常工作。 向读卡器出示适当类型的感应卡。 LED 指示灯会快速呈绿色闪 烁,并且蜂鸣器会发出一次短暂的哔声。 这表示读卡器已正确读 取感应卡。 在控制器处理卡数据后,控制器会使 LED 指示灯呈绿色亮起。 如果读卡器 LED 指示灯由控制器进行控制,请参阅有关 LED 指 示灯操作的控制器说明。 Bosch Sicherheitssyteme GmbH | V 1.2 | 2009.09...
Seite 20
0 至 95% (无冷凝) 尺寸 高 x 宽 x 厚 4.33 x 2.95 x 0.59 英寸 (109.91 x 74.91 x 15 毫米) * 使用博世感应卡 (P/N ACD-ATR11ISO) 或等效产品进行测量。 读取 范围还取决于电气环境和 / 或接近金属情况。 适合室外使用 | V 1.2 | 2009.09 Bosch Sicherheitssyteme GmbH...
Seite 21
ARD-AYH12 安装手册 | zh 安装图 Bosch Sicherheitssyteme GmbH | V 1.2 | 2009.09...
Seite 22
| 安装手册 ARD-AYH12 | V 1.2 | 2009.09 Bosch Sicherheitssyteme GmbH...
Seite 23
ARD-AYH12 Installatiehandleiding | nl Installatiehandleiding De ARD-AYH12 is een RFID-proximitykaartlezer die wordt geïnstalleerd voor gebruik in combinatie met toegangscontrolesystemen. Deze installatiehandleiding bevat de volgende informatie: Bevestigingsinstructies Bedradingsinstructies Bedieningsinstructies Technische specificaties BEVESTIGINGSINSTRUCTIES 1 = Om de bovenkap te verwijderen dient u de schroef van de bovenkap los te draaien, deze bevindt zich onderop de lezer.
Seite 24
UL Klasse 2-conforme voedingsbron of gelijkwaardig. BEDRADINGSINSTRUCTIES De ARD-AYH12 is voorzien van een pigtail met een lengte van 45 cm met een 6-geleidingskabel. Voer de volgende acties uit om de lezer op de controller aan te sluiten:...
Seite 25
Nadat de kaartgegevens zijn verwerkt door de controller, kan deze de LED groen laten worden. Voor werking van de LED, zie de beschrijving van de controller, als de LED van de lezer wordt aangestuurd door de controller. Bosch Sicherheitssyteme GmbH | V 1.2 | 2009.09...
Afmetingen Hoogte x breedte x 109.91 x 74.91 x 15 mm diepte *Gemeten aan de hand van Bosch proximity-kaart (productnummer: ACD-ATR14CS) of gelijkwaardig. Bereik is ook afhankelijk van de elektrische omgeving en de nabijheid van metaal. Geschikt voor gebruik buiten | V 1.2 | 2009.09...
Seite 27
ARD-AYH12 Installatiehandleiding | nl BEVESTIGINGSSCHEMA Bosch Sicherheitssyteme GmbH | V 1.2 | 2009.09...
Seite 28
| Installatiehandleiding ARD-AYH12 | V 1.2 | 2009.09 Bosch Sicherheitssyteme GmbH...
ARD-AYH12 Manual de Instalación | es Manual de Instalación El ARD-AYH12 es una lectora de tarjetas de proximidad RFID que se instala y se utiliza junto con sistemas de control de accesos. Este manual de instalación contiene la siguiente información:...
UL de clase 2 o equivalente. INSTRUCCIONES DE CABLEADO El ARD-AYH12 se entrega con un cable de conexión flexible (pigtail) de 45 mm (18 pulg.) que contiene 6 cables conductores.
Seite 31
Una vez que el controlador ha procesado los datos de la tarjeta, el LED vuelve al color verde. Consulte la descripción de operación del LED incluida con el controlador en caso de que éste gestione el LED de la lectora. Bosch Sicherheitssyteme GmbH | V 1.2 | 2009.09...
Seite 32
109,91 x 74,91 x 15 mm (4,33 x Profundidad 2,95 x 0,59 pulg.) * Medición realizada con una tarjeta de proximidad Bosch (núm. de ref. ACD-ATR11ISO) o un dispositivo equivalente. La distancia también varía en función del entorno eléctrico y la proximidad de elementos metálicos.
