About Thunderbolt 3
Thunderbolt 3 technology uses the USB-C connector, offers bandwidth up to 40Gbps.
It supports USB 3.1, DisplayPort 1.2, and PCI Express 3.0.
Thunderbolt 3 products must be used with Thunderbolt 3 cables.
Your computer's Thunderbolt 3 ports might not function properly until you update one
or more of the following on your computer:
• BIOS
• Thunderbolt firmware
• Thunderbolt 3 controller drivers
• Thunderbolt 3 software
The required updates will vary depending on your computer.
For an up-to-date list of affected computers and instructions, visit
http://
thunderbolttechnology.net/updates. If your manufacturer isn't listed on the
Thunderbolt website, contact your manufacturer.
About DP alt mode (DisplayPort alternative mode)
This docking station supports DP alt mode, which means a DisplayPort video signal
can be transferred over a USB-C cable. Thunderbolt 3 supports the full USB-C standard,
including support for DP alt mode. Because the docking station supports DP alt mode,
you can connect Thunderbolt 3 or USB-C based video devices, cables, or adapters to
the secondary Thunderbolt 3 port on the rear of the docking station.
Thunderbolt temperature
Due to the high-performance of Thunderbolt technology, Thunderbolt products
sometimes generate more heat than traditional hardware. Therefore, it's normal for
the docking station to warm up when in use. As such, it's recommended that you
don't place your laptop on the docking station's surface, as doing so will result in even
higher temperatures.
These higher temperatures do not represent a safety hazard to users or to hardware.
About USB 3.0 and USB 3.1 Gen 1
USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard offers speeds up
Instruction manual
3
