Visit
www.StarTech.com/AV/usb-c-video-adapters/
and cables.
Notes:
• You can connect two 4K displays, or a single 5K Thunderbolt 3 display to the
docking station.
• The maximum available resolution may be limited if your monitor is connected
through a video adapter. Check the documentation of the video adapter to
determine its maximum supported resolution.
Connect multiple Thunderbolt 3 displays in a daisy chain
You can also set up dual displays using multiple Thunderbolt 3 displays in a daisy-
chain configuration. For example, you can connect a Thunderbolt 3 display to
the Thunderbolt 3 port on the docking station. You can then connect another
Thunderbolt 3 device, such as a second Thunderbolt 3 display, through the first
Thunderbolt 3 display.
Supported video resolutions
Thunderbolt technology supports both video and data throughput. However, it
prioritizes video bandwidth to help ensure seamless display performance. The
performance of the remaining dock functions depends entirely on the display
configuration you used.
The docking station supports the follow maximum resolutions:
Number of
Displays
1
1
1
2
• Depending on the configuration and the supported resolutions of your connected
monitor(s), the docking station can support video resolutions lower than specified
above.
Instruction manual
Ports
DisplayPort port
Thunderbolt 3 port
Thunderbolt USB-C port
(using DP alt mode)
DisplayPort port and
Thunderbolt 3 USB-C
port
for a range of USB-C video adapters
Maximum Resolution
4096 x 2160p ( up to 60Hz)
5120p x 2880p (60Hz)
(Thunderbolt 3 monitor only)
4096 x 2160p ( 60Hz)
4096 x 2160p (up to 60Hz) and
4096 x 2160p (60Hz)
8
