Introduction
The TB3DKDPMAW and TB3DKDPMAWUE integrate Thunderbolt™ 3 technology to
offer throughput at speeds up to 40Gbps. You can use this dock to connect dual-4K
monitors (60Hz) to your Thunderbolt 3 equipped laptop or MacBook. This dock also
features a range of input and output ports, such as DisplayPort, Gigabit Ethernet, USB
fast-charge, USB 3.0, USB-C™, headphone, microphone, and Thunderbolt 3.
Package contents
• 1 x Thunderbolt 3 docking station
• 1 x Thunderbolt 3 cable - 40Gbps - 0.5m
• 1 x universal power adapter
• 2 x power cords (NA/JP, ANZ for TB3DKDPMAW) (EU, UK for TB2DKDPMAWUE)
• 1 x instruction manual
Requirements
• Host laptop with an available Thunderbolt 3 port
• Available AC electrical outlet
• DisplayPort equipped display(s) with cable(s) as needed (for additional external
display)
• Thunderbolt 3 equipped display(s) with cable(s) as needed (for additional external
display)
• For dual-display configurations: You must use one of the docking station's
Thunderbolt 3 ports. You may need to purchase a separate adapter to connect an
HDMI, a DVI, or VGA display. See the "Configure a display device" section for more
details. Your laptop hardware must also support dual external displays through its
Thunderbolt 3 port.
• For 4K (4096 x 2160p) resolution, a 4K-capable display is required
• For 5K (5120 x 2880p) resolution, a 5K-capable display is required
• Any of the following operating systems:
• Windows® 10 (32-bit or 64-bit)
• Windows 8 / 8.1 (32-bit or 64-bit)
• Windows 7 (32-bit or 64-bit)
• macOS 10.12 (Sierra)
Requirements are subject to change. For the latest requirements, please visit
www.StarTech.com/TB3DKDPMAW
Instruction manual
or www.StarTech.com/TB3DKDPMAWUE.
1
