CAD manufactured high performance antennas - Made in Germany -
• multiple-optimized design according to DL6WU
• all holes of the boom drilled automatically by robot - extreme small tolerances
• Elements automatically cut, length tolerance less than max. 0.1 mm Elements are exactly
centered and automatically mounted by robot
• Non-compromise dipole: pwr Rating 500W SSB/CW, N-jack, balun made of semi-rigid cable, all
connectors sealed, connection box additionally filled.
The antennas have an enormous high f/b ratio because of the use of 8 reflectors. This is in particu-
lar important for high-gain yagis: even the highest gain gets useless if unwanted signals or interfer-
ences are being received from the back side of the antenna. EME or SAT freaks enjoy our anten-
nas due to the low backward noise scatter (from the surface of the earth). All nuts, bolts and wash-
ers are manufactured of stainless steel. Even the mast clamp is made of stainless steel (where
else do you find this?).The antennas are supplied pre-assembled with all elements already in
place. They can be assembled in about 10 minutes; you don't have to read the manual and it does
not take an engineering approach to install the antenna and get into the air...
Technical Data
Typ SHF...
Frequency
No. Elements
gain ISO
gain dBD
length
electr. Length
3 dB beamwidth
side lobes
F/B ratio
stacking distance
VSWR typ.
mast dia. max.
windload (120km/h)
shipping length
connector
Fore-mast
support strut
part no.
WiMo Antennen und Elektronik GmbH
Am Gäxwald 14 D-76863 Herxheim
http://www.wimo.com
SHF-design
Yagi Antennas
23cm
2328
2344
2367
1240-1300 MHz
28
44
67
17,5
20,2
22
15,4
18,1
19,9
1,6
3,0
5,1
6,5
13
22
21,8°
16,5°
13,7°
-17
-17
-17
26
26
27
570
751
913
1,2
1,2
1,2
52
52
52
38
86
134
1,6
1,6
2,65
N - jack
☺
☺
☺
18401
18403
18405
- 6 -
13cm
1340
1367
2300-2450 MHz
40
67
18,7
22,1
16,6
20,0
1,6
3,0
9,3
22,7
18,8°
13,2°
-16
-16
25
25
391
522
1,2
1,2
52
52
55
90
1,6
1,55
N jack
☺
☺
18410
18415
Tel.(07276) 96680 FAX: 966811
e-mail: info@wimo.com
