If the antennas are to be stacked, take care of the phase! If one antenna is to be mounted
upside down, there are two solutions to eliminate the 180° phase shift:
• one of the feedlines must be made ½ wavelength longer, but take care of the velocity
factor! Not so easy on 2.4 GHz...
• we supply special dipoles with 180° phase shift for some surcharge.
parts list
Typ SHF...
part no.
No. elements
1
boom (rear)
2
boom (front)
3
reflector assembly
4
reflector clamp
5
support strut
6
dipole
7
boom joint
8
U-bolt
9
mast clamp
10
fixing clamp
11
Boom clamp
12
screw M3 x 20
13
screw M3 x 6
14
screw M4 x 8
15
screw M6x12
16
screw M6x30
17
screw M6x40
18
washer 3mm
19
washer 6mm
20
big washer 6mm
21
lockwasher 3mm
22
lockwasher 4mm
23
lockwasher 6mm
24
nut M6
25
wingnut M6
26
spacing tube
27
leaflet
RE: SHF 2367 23cm 67ele
To save freight charges, we supply cut-down versions by default: additional 3 sets of boom
joints and screws are provided. Support strut and boom parts are to be spliced as shown
above for the regular model. This improvement is NOT shown in the assembly instructions
above.
WiMo Antennen und Elektronik GmbH
Am Gäxwald 14 D-76863 Herxheim Tel. (07276) 96680 FAX: 966811
http://www.wimo.com
- 10 -
2310
2328
2344
18400
18401
18403
10
28
44
1
1
1
-
-
1
-
2
1
-
2
1
-
-
1
1
1
1
-
-
2
1
1
2
1
1
1
1
1
-
1
1
-
2
2
2
-
6
5
-
-
-
2
2
-
-
-
4
-
-
2
2
2
2
2
2
16
2
2
-
-
6
3
-
-
-
-
-
10
-
-
10
2
2
-
1
1
1
1
1
1
2367
1340
1367
18405
18410
1841
67
40
1
1
1
1
-
1
1
2
1
1
2
1
1
-
1
1
1
1
2
-
2
2
1
2
1
1
1
-
1
-
-
1
-
2
2
2
5
4
3
-
2
-
-
2
-
4
-
4
2
-
2
2
2
2
16
2
16
-
2
-
3
4
3
-
2
-
10
-
10
10
-
10
-
2
-
1
1
1
1
1
1
