3. Initial start-up

3.2. Fastening on the VESA bracket

For fastening the monitor on a bracket, the foot can be removed as follows:
Diagram
When mounting the VESA bracket, please observe that the screws (M4) must not protrude
into the appliance by more than 10 mm max.
Procedure
Place the appliance cautiously onto an even
surface. If necessary, put a soft cloth underneath
to prevent the LED screen from becoming
scratched.
Remove the foot by unscrewing the two screws
on the back side of the foot.
