Unite CC-24P – Charging Case
4.3 Charging
1. Set the switch to "Charge only".
2. Insert the bodypack receivers / transmitters into the charging compartments so that the charging contact of the transmitters
/ receivers have contact with those in the charging module.
3. Charging will start automatically.
4. The state of charge of the batteries is indicated by the LED of the appropriate device:
Indicator light
Off
Flashing green slowly
Green
Flashing yellow slowly
Yellow for 10 seconds
Flashes red slowly for 10 seconds
Flashing green/yellow rapidly
Flashing red rapidly
Charging status
Device is switched off
Charging 0 - 100%
Battery is charged
Pairing information is being copied from the transmitter
Device information is copied successfully to charger/devices
• Too many transmitters in the charger when pairing is initiated
• Other pairing error
Device is being localised
Charging error
