Unite CC-24P – Charging Case
4. How to operate the charging case
The Unite CC-24P charging case is used for charging the rechargeable batteries inside the bodypack transmitters and
receivers as well as transmitting the pairing information from the transmitter to the receivers. The Unite CC-24P features a
modular design and can accommodate a maximum of 6 charging modules, each with 4 charging compartments so that a
maximum of 24 bodypack transmitters or receivers can be charged simultaneously. If you do not need 6 charging modules,
you can install an appropriate number of blank panels. Furthermore, the Unite CC-24P provides room for up to 3 more
optional charging modules each with 4 charging compartments so that a maximum of 36 charging compartments is
available.
4.1 Mains connection
• Connect the IEC connector of the power cable to the mains connection of the charging case. Connect the power plug to a
power outlet.
• Switch on the charging case via the on-off switch.
• When not in use, switch off the device and disconnect the power plug from the power socket. Make sure that you do not
pull on the cable, but on the power plug.
4.2 Establish pairing
In order to perform a simple pairing, proceed as described in the following:
1. Set the desired group ID on the transmitter you want to use for pairing. Refer also to chapter 5.2 of the "Unite TP – Body-
pack Transmitter".
2. Insert only one transmitter into the charging compartment of the charger. If multiple transmitters are inserted into the
charging compartments, the pairing will not start and the status indicator
table). Alternatively, you can connect the transmitter to the USB port, type C on the charger via a USB cable.
3. Insert one or more receivers into the charging compartments of the charger to be paired with the transmitter. You can
also connect another receiver to the charger using the USB port. Remove all receivers that should not be paired. If
there is no receiver in the charging compartments, the pairing information is stored in the charger. This is used for later
pairing without connecting the transmitter to the charger.
4. In order to transfer the pairing information from the transmitter to the receivers in the slots and to the charger itself for
future pairing, press and hold the "Pair/Reset" button
on the charger will display an error (see
on the charger for more than 2 seconds. The status indicator
