Electrical actuators type EA 11/ 21/ 31/ 42

6.3 Identification

1 Type label (e. g. EA31)
2
Order number
3 Housing material
4 Voltage type

6.4 Position indicator

The position indicator displays the valve position. The valve position can be read on
the fitted cover.
GF actuators are always delivered in the "Open" position.
When the cover is fitted, the following image can be seen:
"Closed" position
"Open" position
5
6
7
8
2-way
3-way horizontal
C
A-B
Design and function
Duty cycle/protection type
Nominal output
Serial number
Approvals & CE-mark
B – C
A – C
3-way vertical
A – C
B – C
45
