1. Use
•
Tempering of church pews, office desks, shop boxes
•
The panels can be installed on flammable materials.
2. Wiring
•
Power supply: 230V/50Hz
•
Protection class I
•
IP 44
•
The panel is fitted with a thermal fuse.
3. Installing
•
The panels are intended for vertical installation. In case of horizontal installation on the ceiling of a room, hang the panel
on a mounting frame (not included in the package), or using chains or cords.
•
The minimum distance of the panel front wall and lateral walls from inflammable objects is 10 cm.
Procedure — vertical mounting:
•
Mark the holes according to the table, drill out the holes, insert the dowels and drive the screw in to protrude
approx. 5 mm.
•
Always fix the panel on two upper locks, two lower locks serve to a reverse suspension of the panel.
•
Connect the lead-in cable to a fixed power distribution in accordance with the colour marking of wires.
•
Put the panel on the two upper locks.
Procedure – horizontal mounting
•
Position the mounting frame in the location where the panel is to be placed, using a pen, mark holes according to the
holes on the frame.
•
Drill the holes, insert the wall anchors and attach the mounting frame with the screws.
•
Connect the lead-in cable to the mains in accordance with the color of the conductors.
•
Slide the panel into the mounting frame.
