LIST OF CONNECTORS AND COMPATIBILITIES
Mini USB Compatible with the Motorola™ / Blackberry™
telephones and other devices using mini USB connec-
tors, i.e. MP3 players, Bluetooth headset, etc.
DS™lite Compatible with the Nintendo DS™lite console.
DSi™ Compatible with the Nintendo DSi™ console.
PSP® Compatible with the Sony® PSP®
(1000, 2000 and 3000 series) console.
Nokia® Compatible Nokia® mobile phones using
(standard) standard connections.
Nokia® Compatible with Nokia® mobile phones using
(mini plug) mini plug connectors.
Motorola™ Compatible with mobile phones using Motorola™
connectors.
Sony Compatible with mobile phones using
Ericsson™ Sony Ericsson™ connectors.
Samsung™ Compatible with mobile phones using
Samsung connectors™.
Exception : for the iPod™ and iPhone™, use the USB cable supplied
with your Apple device.
-----------------------------------------------------------------------------------

FUNCTIONS AND OPERATION.

Charging the internal battery
Once the Multipowerbox is connected to mains power, the "Bigben
Interactive" logo will light up.
The dotted lines on the face of the Multipowerbox will light up
(levels 1 to 4), depending on the internal battery's charge level. [3]
The lights will then flash until the internal battery is full.
The 4th level indicates that the battery is completely charged. The
dotted lines will then switch off and the logo will remain lit to indicate
that the MultiPowerbox is still on.
Using as a Mains adaptor / charger
Firstly select the correct connector for your device and connect to
the charging end of the USB cable.
Then connect the USB connector to the Multipowerbox. For Apple
devices, like Ipod™ and Iphone™, you need to use the original cable
that was supplied with your device. [4]
Select the correct power setting for your device. (Hi or Lo) You may
need to refer to your devices instructions or original mains adaptor
to find the correct setting. [5]
If you are not sure, set the MultiPowerbox to Lo mode. This will not
cause a problem as it will not function with your device. You can then
set it to Hi mode if power or charging does not work. Please check
the specification list above for the Hi \ Lo output voltages.
Connect the MultiPowerbox to the mains power and your device
will now operate. If the rechargeable battery in your device is low,
charging will start immediately. Charging indication will operate as
normal, usually indicated by flashing lights, or an on-screen display,
on your product.
Using as a portable charger
You can use your MultiPowerbox anywhere, providing you have
charged it before use. To check the charge level of your internal
battery, simply press the silver button on the front. [6]
The charge level lights indicate to show you how much battery power
remains. Attach the USB cable to the MultiPowerbox and to your
device, as instructed above, ensuring you have it set to the correct
Hi or LO setting. Charging will then continue until your device is fully
charged or the internal battery charge is depleted.
