c) Charging the mobile device
• Connect the micro-USB socket (4) to your mobile device/ smartphone via the included charg-
ing cable.
• Press the button (6) briefly to enable the charging function. The green LED "C" lights up (if no
device is connected or no charging current is detected, the green LED "C" will go out after a
few seconds).
The micro-USB output now supplies voltage/ current (5 V/DC, max. 1 A) to the connected
mobile device/ smartphone, whose charging function has to start. Check its display.
• Monitor the charging process. Once the mobile device/ smartphone is fully charged (or the
rechargeable battery of the solar-powered torch is empty), the charging function of the solar-
powered torch will turn off.
The mobile device may not be completely charged as the capacity of the recharge-
able battery in the solar-powered torch may be lower than that in the mobile device.
• If a single red LED flashes, the battery of the solar-powered torch is empty. The charging
process will be automatically terminated to protect the battery from deep discharge.
• To stop charging, disconnect the cable connection between your mobile device/ smartphone
and the solar-powered torch by unplugging the micro-USB connector of the charging cable
from the port on the solar-powered torch.
d) Using the torch function
• To activate the torch function, press and hold down the button (6) (for about 3 seconds) until
the four white LEDs (1) light up. Then, release the button again.
The red LEDs show the current charge level of the built-in rechargeable battery for a few
seconds and then turn off.
• Briefly press the button (6) to switch between continuous and flashing light modes.
• To turn off, press and hold down the button (6) (for about 3 seconds) until the white LEDs go
out.
Maintenance and cleaning
The product does not require any maintenance and should never be disassembled for any
reason. The rechargeable battery is permanently installed and cannot be replaced.
Clean the product carefully, e.g. with a soft, clean cloth. Dust can be easily removed with a soft,
clean brush and a vacuum cleaner.
Never use aggressive cleaning agents or any chemicals at all for cleaning; these can lead not
only to discolouration, but can also damage the product.
Disposal
Electronic devices are recyclable material and do not belong in the household waste.
Please dispose of the device, when it is no longer of use, according to current statu-
tory requirements.
Technical data
Input voltage/current ....................... 5 V/DC, max. 500 mA
Output voltage/current .................... 5 V/DC, max. 1 A
Charging input/output ..................... 1x micro-USB socket
Charging time ................................. via USB: about 5 h, via solar cell: about 16.5 h
Built-in rechargeable battery ........... Li-Po, 2000 mAh
Light flux ......................................... 25 - 30 lm
Lighting duration ............................. max. 25 h (continuous light) or max. 35 h (flashing light)
Ambient conditions ......................... temperature 0 °C to +45 °C, relative humidity 10% to 85%
Dimensions (L x W x H) .................. 130 x 60 x 9 mm
Weight ............................................ 91.5 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent
the technical status at the time of printing.
© Copyright 2015 by Conrad Electronic SE.
