I/O P I/O Panel (N68C I/O P anel (N68C anel (N68C-S UCC) anel (N68C
I/O P I/O P anel (N68C
1 PS/2 Mouse Port (Green)
2 RJ-45 Port
3 Line In (Light Blue)
4 Front Speaker (Lime)
5 Microphone (Pink)
* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.
LAN Port LED Indications
Activity/Link LED
Status Description
Off No Activity
Blinking Data Activity
To enable Multi-Streaming function, you need to connect a front panel audio cable to the front
panel audio header. After restarting your computer, you will find "VIA HD Audio Deck" tool on
your system. Please follow below instructions according to the OS you install.
For Windows ® XP / XP 64-bit OS:
Please click "VIA HD Audio Deck" icon
select "2 Channel" or "4 Channel". Click "Power" to save your change.
For Windows ® 7 / 7 64-bit / Vista
Please click "VIA HD Audio Deck" icon
on the bottom. In "Advanced Options" screen, select "Independent Headphone", and click
"OK" to save your change.
4 4 4 4 4
ASRock
-S UCC) -S UCC) -S UCC)
-S UCC)
6
7
8
9
10
SPEED LED
Status Description
Off 10Mbps connection
Green or 100Mbps connection
Orange
, and click "Speaker". Then you are allowed to
TM / Vista TM 64-bit OS:
, and click "Advanced Options" on the left side
N68C-GS UCC / N68C-S UCC
USB 2.0 Ports (USB01)
USB 2.0 Ports (USB23)
VGA Port
COM Port
PS/2 Keyboard Port (Purple)
ACT/LINK SPEED
LED LED
LAN Port
Motherboard
