The installation of your new be quiet! Straight Power power supply:
1. Place the new power supply in the space provided in the case and screw it into the backside with the four
screws included with the delivery. Do not use excessive force to do this.
2. Place the 20/24 pin into the intended connector on the mainboard. If you have a 24 pin connection, then place
the remaining 4 pins in the correct position before you stick the connector in the socket. When using a 20 pin
connector, fit the additional 4 pins right into the side.
3. Now stick the 4 pin connector, also called the P4 connector, into the provided socket on the mainboard. This
connector is will provide your CP in the future with additional electricity.
4. If you have a mainboard with several processors, you will require the additional 8 pin EPS connectors. You
connect these into the socket on the mainboard.
Remarks: Please observe the your mainboard manufacturer instructions when connecting the EPS connector . Not
all mainboards dispose of these connections.
FAN
The two fan connections are indicated with FAN. The fan connections are to be attached at these junctions. The
attached fans are later controlled by the internal automatic controls.
Attention: only one fan per connection cable!
Maximum load for all connections in sum 0.8A/9.6W!
(available as of 450W)
P8 CONNECTOR
The P8 connector is required for mainboards with several processors. These provide the processors with an extra
12V circuit that is required for a stable operation.
PCIE1 AND PCIE2
The use of two PCI EXPRESS graphic cards in a SLI or Crossfire network is fully assured by up to two PCI EXPRESS
power connections. (500 Watts and above)
SATA
be quiet! power supplies in the STRAIGHT POWER series are fitted with up to 8 fully wired SATA power connections,
including 3.5V cable.
You are thus best equipped for the future and any further additions to your system. (8 SATA are available for the
550W model and above)
5 . S P E C I F I C AT I O N S

1. VOLTAGE REGULATION

T e c h n is c h e D a t e n
D C A u s g a n g
S p a n n u n g s r e g u lie r u n g
A T X F o r m F a c t o r A T X 1 2 V V 2 . 2
A C S p a n n u n g 1 1 0 - 2 4 0 V a c
F r e q u e n z
P F C T y p a k t iv e P F C
P F W e r t 0 , 9 9 b e i 1 0 0 % L a s t
D C S c h ie n e
+ 3 , 3 V
+ 5 V
+ 1 2 V
1
+ 1 2 V
2
- 1 2 V
+ 5 V S B
+ 1 2 V 3
+ 1 2 V 4

5 0 - 6 0 H z
T o le r a n z R e g e lb e r e ic h e
+ /- 5 % 3 , 1 4 V ~ 3 , 4 7 V
+ /- 5 % 4 , 7 5 V ~ 5 , 2 5 V
+ /- 5 % 1 1 , 4 V ~ 1 2 , 6 V
+ /- 5 % 1 1 , 4 V ~ 1 2 , 6 V
+ /- 1 0 % - 1 0 , 8 V ~ - 1 3 , 2 V
+ /- 5 % 4 , 7 5 V ~ 5 , 2 5 V
+ /- 5 % 1 1 , 4 V ~ 1 2 , 6 V
+ /- 5 % 1 1 , 4 V ~ 1 2 , 6 V
