Inhaltszusammenfassung für BE QUIET! Straight Power 11 1000W

  • Seite 1 USER MANUAL 1000W 850W 750W 650W 550W 450W...
  • Seite 3 INDEX Glinde, V1/21 ENGLISH » Introduction ����������������������������������������������������������������������������������������������������������������������������������������������������������5 Safety instructions ����������������������������������������������������������������������������������������������������������������������������������������������5 Compatibility ��������������������������������������������������������������������������������������������������������������������������������������������������������5 Installing your new power supply �������������������������������������������������������������������������������������������������������������������������5 Safety functions ���������������������������������������������������������������������������������������������������������������������������������������������������6 Troubleshooting ����������������������������������������������������������������������������������������������������������������������������������������������������6 Frequent problems �����������������������������������������������������������������������������������������������������������������������������������������������7 Accessories ����������������������������������������������������������������������������������������������������������������������������������������������������������7 Notes on disposal �������������������������������������������������������������������������������������������������������������������������������������������������7 Warranty* �������������������������������������������������������������������������������������������������������������������������������������������������������������8 Manufacturer’s details �����������������������������������������������������������������������������������������������������������������������������������������8 Copyright ��������������������������������������������������������������������������������������������������������������������������������������������������������������8 Technical data ����������������������������������������������������������������������������������������������������������������������������������������������������32 DEUTSCH »...
  • Seite 4 Funkcje bezpieczeństwa ������������������������������������������������������������������������������������������������������������������������������������20 Usuwanie usterek �����������������������������������������������������������������������������������������������������������������������������������������������20 Częste problemy �������������������������������������������������������������������������������������������������������������������������������������������������21 Akcesoria ������������������������������������������������������������������������������������������������������������������������������������������������������������ 21 Wskazówki dotyczące recyclingu �����������������������������������������������������������������������������������������������������������������������21 Gwarancja* ���������������������������������������������������������������������������������������������������������������������������������������������������������22 Dane Producenta ������������������������������������������������������������������������������������������������������������������������������������������������22 Prawa Autorskie �������������������������������������������������������������������������������������������������������������������������������������������������22 Dane techniczne �������������������������������������������������������������������������������������������������������������������������������������������������32 ESPAÑOL » Introducción �������������������������������������������������������������������������������������������������������������������������������������������������������23 Indicaciones de seguridad ��������������������������������������������������������������������������������������������������������������������������������23 Compatibilidad ���������������������������������������������������������������������������������������������������������������������������������������������������23 Instalación de su nuevo bloque de alimentación �����������������������������������������������������������������������������������������������23 Funciones de fusible ������������������������������������������������������������������������������������������������������������������������������������������24 Solución de errores ��������������������������������������������������������������������������������������������������������������������������������������������25 Problemas frecuentes ����������������������������������������������������������������������������������������������������������������������������������������25...
  • Seite 5 INTRODUCTION We are delighted that you have chosen to use a be quiet! power supply from our Straight Power 11 series in your PC� Please read and follow all the information contained in these instructions carefully prior to installation� Should you have any further question, please contact our customer service� See contact information in item Manufacturer’s details�...
  • Seite 6 Caution: Only use the supplied cable set� Using cables that were not included (e�g� cables of older power supply unit series) may lead to defects! First remove your old power supply. To do so, proceed as follows: ∙ Carefully disconnect your PC from any power sources and unplug all cables connected to the PC� ∙...
  • Seite 7 cables and exposure to liquids, immediately disconnect the power from the mains and do not use it again� Never open the power supply case� High-voltage components in the interior of the power supply may still be live after a longer period of disuse� Please have any and all necessary repairs conducted by an authorized expert! Opening the device will void your warranty.
  • Seite 8 ** Corresponds to the law on sale, return and sustainable disposal of electrical and electronic equipment (Electrical and Electronic Equipment Act – ElektroG) 10. WARRANTY ∙ 5-year manufacturer’s warranty for consumers (original purchase from authorised be quiet! dealers only)� ∙ Your original purchase receipt will be required before warranty performance is rendered. Please keep it in a safe place�...
  • Seite 9 EINLEITUNG Wir freuen uns, dass Sie sich dazu entschieden haben, ein be quiet! Netzteil der Straight Power 11 Serie in Ihrem Rechner einzusetzen� Vor der ersten Inbetriebnahme befolgen Sie bitte alle Punkte dieser Anleitung� Falls Sie weitere Fragen haben, richten Sie diese gerne an unseren Kundenservice� Siehe hierzu Kontaktdaten unter „Herstellerangaben“�...
  • Seite 10 INSTALLATION IHRES NEUEN NETZTEILS Lesen Sie bitte den Punkt „Sicherheitshinweise“ bevor Sie mit der Installation beginnen� Anmerkung: Zum Einbau des Netzteils in Ihren PC benötigen Sie einen Schraubendreher� Benutzen Sie nur die mitgelieferten Schrauben aus dem Lieferumfang, da diese über das richtige Gewinde verfügen� Achtung: Verwenden Sie nur den mitgelieferten Kabelsatz! Das Verwenden von nicht mitgelieferten Kabeln (z�B�...
  • Seite 11 OPP (Überlastschutz) Diese Sicherung löst aus, sobald die gesamte Leistung, welche vom Netzteil abgenommen wird, die spezifizierte Höchstlast übersteigt� Dieser Fall kann eintreten, wenn das Netzteil nicht über genügend Leistung für das System verfügt (unterdimensioniert ist)� FEHLERBEHEBUNG Bitte beachten Sie: Bei ATX-Systemen wird das Netzteil vom Mainboard aktiviert, um den PC zur starten. Daher prüfen Sie bitte, entweder mit Hilfe des Mainboards- oder des Gehäusehandbuches, ob der Ein- / Ausschalter korrekt verbunden wurde�...
  • Seite 12 ENTSORGUNGSHINWEISE Gebrauchte Elektro- und Elektronikgeräte dürfen gemäß europäischer Vorgaben* nicht mehr zum unsortierten Siedlungsabfall gegeben werden� Sie müssen getrennt erfasst werden� Das Symbol der Abfalltonne auf Rädern mit Balken weist auf die Notwendigkeit der getrennten Sammlung hin� Helfen auch Sie mit beim Umweltschutz und sorgen Sie dafür dieses Gerät in die hierfür vorgesehenen Systeme der Getrenntsammlung zu geben, wenn Sie es nicht mehr weiter nutzen wollen�...
  • Seite 13 ∙ be quiet! ist eine eingetragene Marke der Firma Listan GmbH� Andere in dieser Dokumentation erwähnten Produkte- und Firmennamen können Marken oder Handelsnamen ihrer jeweiligen Eigentümer sein� ∙ Listan entwickelt entsprechend ihrer Politik die Produkte ständig weiter� Listan behält sich deshalb das Recht vor, ohne vorherige Ankündigungen jedem der in dieser Dokumentation beschriebenen Produkte Änderungen und Verbesserungen vorzunehmen�...
  • Seite 14 INTRODUCTION Nous vous remercions d'avoir choisi un bloc Straight Power 11 de be quiet!� Avant la première mise en service, nous vous recommandons de lire attentivement ce manuel et d’en observer les consignes� Si vous avez d’autres questions, nous vous invitons à prendre contact avec notre service après-vente, dont vous trouverez les coordonnées dans la rubrique «...
  • Seite 15 Remarque : vous aurez besoin d’un tournevis pour effectuer l’installation de votre bloc d’alimentation. Utilisez exclusivement les vis livrées avec votre bloc car elles présentent le filetage requis. Attention : veuillez utiliser uniquement les câbles fournis avec votre alimentation� Utiliser d’autres câbles peut s’avérer dangereux et peut entraîner des défaillances�...
  • Seite 16 DÉPANNAGE Remarque : veuillez noter qu’avec un système ATX, l’alimentation est activée par la carte mère pour démarrer votre PC. Il convient donc de suivre le manuel d’utilisation de la carte mère et/ou du boîtier pour vérifier si l‘interrupteur marche/arrêt est correctement câblé. Attention : manipuler des éléments sous tension comporte un risque de blessures graves voire mortelles.
  • Seite 17 CONSIGNES D’ÉLIMINATION ET DE RECYCLAGE En application des directives européennes*, les appareils électriques et électroniques usagés ne peuvent plus être jetés avec les déchets ménagers� Ils doivent être triés, comme l’indique le symbole du conteneur à déchets barré d’une croix� Contribuez vous aussi à...
  • Seite 18 ∙ Listan procède au développement continu de ses produits conformément à sa politique� Par conséquent, Listan se réserve le droit de procéder à des modifications et améliorations de chacun des produits décrits dans la présente documentation, sans aucun préavis� ∙ Listan décline toute responsabilité en cas de pertes de données et de revenus, de dommages particuliers, accessoires, directs ou indirects, quels qu’ils soient, et quelle qu’en soit l’origine�...
  • Seite 19 WPROWADZENIE Cieszymy się, że zdecydowali się Państwo na zamontowanie w swoim komputerze zasilacza be quiet! serii Straight Power 11. Aby od razu odpowiedzieć na Państwa ewentualne pierwsze pytania, opisaliśmy zalety i cechy szczególne serii zasilaczy Straight Power 11 w niniejszej instrukcji obsługi. Dalsze pytania prosimy kierować...
  • Seite 20 wraz z zasilaczem, gdyż posiadają one odpowiednie gwinty. Uwaga: Należy używać wyłącznie dostarczonego zestawu kabli. Używanie kabli innych niż dostarczone (np. kabli starszych serii zasilaczy) może doprowadzić do usterki! Najpierw należy wymontować stary zasilacz. W tym celu należy postępować następująco: ∙...
  • Seite 21 Uwaga: W celu uruchomienia komputera w przypadku systemów ATX zasilacz jest włączany przez płytę główną. Dlatego proszę się upewnić, z pomocą podręcznika użytkownika płyty głównej lub obudowy, czy włącznik/wyłącznik został poprawnie podłączony. Uwaga: Praca przy źródłach prądu może prowadzić do urazów zagrażających życiu. W razie wystąpienia smug dymu, uszkodzenia kabli oraz kontaktu z substancjami ciekłymi należy natychmiast wyłączyć...
  • Seite 22 używać, trafiło na specjalne wysypisko odpowiednie dla takich odpadów. W Niemczech są Państwo ustawowo** zobowiązani do przekazywania starych urządzeń na specjalne dla tych celów wysypisko. Podmioty odpowiedzialne w świetle prawa publicznego za przetwarzanie odpadów (gminy) stworzyły w tym celu specjalne punkty zbioru, w których stare urządzenia pochodzące z gospodarstw prywatnych danego obszaru są...
  • Seite 23 INTRODUCCIÓN Gracias por haber escogido un bloque de alimentación be quiet! de la serie Straight Power 11 para su ordenador� Antes de usar el dispositivo por primera vez, siga todos los puntos de este manual� Si tiene más dudas, consulte a nuestro servicio de atención al cliente� Para ello, vea los datos de contacto del punto Datos del fabricante�...
  • Seite 24 Atención: Use sólo el conjunto de cables suministrado! El uso de otro tipo de cables (como por ejemplo, el de una fuente de alimentación más antigüa) puede dañar la unidad! Primero, desmonte el antiguo bloque de alimentación. Para ello, proceda del siguiente modo: ∙...
  • Seite 25 SOLUCIÓN DE ERRORES A tener en cuenta: En los sistemas ATX, la placa base activa el bloque de alimentación para iniciar el PC� Por lo tanto, compruebe si el interruptor de encendido/apagado está bien conectado con ayuda del manual de la placa base o la caja�...
  • Seite 26 En Alemania, está obligado** por ley a desechar un dispositivo usado por separado de la basura convencional sin clasificar. Las empresas públicas encargadas de recoger la basura (municipios) han creado puntos de recogida donde se pueden reciclar los dispositivos domésticos usados de forma gratuita� También es posible que estas empresas de recogida de basura vayan a buscar los dispositivos usados a los domicilios particulares�...
  • Seite 27 ВВЕДЕНИЕ Мы рады, что вы выбрали блок питания Straight Power 11 серии производства be quiet! для вашего ПК� Пожалуйста, прочтите и следуйте информации, представленной в данной инструкции� Если у вас возникнут дополнительные вопросы, пожалуйста, свяжитесь со службой поддержки пользователя� Контактную информацию...
  • Seite 28 ∙ Осторожно отсоедините компьютер от любых источников питания и отключите все кабели, подключенные к компьютеру� ∙ Откройте корпус ПК, внимательно следуя инструкции производителя� ∙ Отсоедините все разъемы от системной платы и других компонентов, таких как FDD, жесткие диски или оптические приводы� Убедитесь, что все кабели от старого блока питания отсоединены от компонентов системы�...
  • Seite 29 ∙ Убедитесь, что сетевой кабель электропитания правильно и надежно подключен к порту питания и розетке� Оптимально использовать отдельную розетку для питания компьютера� ∙ Убедитесь, что все разъемы правильно подключены и внесите коррективы, например, в случае неправильной полярности� ∙ Проверьте соединение выключателя корпуса с системной платой� При необходимости обратитесь к инструкции...
  • Seite 30 10. ГАРАНТИЯ ∙ 5-летняя гарантия производителя для потребителей (для оборудования, купленного только у авторизованных представителей be quiet!)� ∙ Для гарантийного случая потребуется оригинальная квитанция, подтверждающая факт покупки� Пожалуйста, храните ее в надежном месте� ∙ Открытие корпуса устройства, манипуляции и/или технические изменения любого рода и повреждения из-за...
  • Seite 31 Limited Warranty Per the terms and conditions of this limited warranty as given below, be quiet! warrants its new products to be free of defects resulting from faulty materials and faulty manufacturing for the length of the warranty period� I. APPLICABILITY This non-transferable warranty is applicable to newly purchased, previously unopened be quiet! products and is enforceable by only the original consumer purchaser�...
  • Seite 32 100 - 240Vac 50 - 60Hz 6 - 3A AC Input TECHNICAL DATA 100 - 240Vac 50 - 60Hz 6 - 3A AC Input DC Output 12V1 12V2 -12V 5VSB 3.3V 12V3 12V4 100 - 240Vac 50 - 60Hz 6 - 3A AC Input Technische Daten, Données technique, Datos técnico, Dane technicze, DC Output...
  • Seite 33 VOLTAGE REGULATION DC Output 3�3V 12V1 12V2 12V3 12V4 -12V 5VSB Tolerance +/- 3% +/- 3% +/- 3% +/- 3% +/- 3% +/- 3% +/- 4% +/- 3% Ripple/Noise (max.) 40mV 40mV 80mV 80mV 80mV 80mV 80mV 40mV OPERATING CONDITIONS Environment Temperature Rel.
  • Seite 34 DIMENSIONS 86mm 160mm (450-650W) | 170mm (750-1000W) DISTRIBUTION AND PIN ASSIGNMENT 24 PIN ATX power connector Signal Signal +3�3VDC +3�3VDC +3�3Vdef�sense +3�3VDC -12VDC +5VDC PS_ON/OFF +5VDC PWR_OK +5VSB +5VDC +12VDC +5VDC +12VDC +5VDC +3�3VDC...
  • Seite 35 +12V power connector E P S + 1 2 V P O W E R C O N N E C T O R Signal Signal Color Signal Color Signal Yellow +12VDC Black +12VDC Yellow +12VDC Black Yellow +12VDC Black +12VDC Yellow +12VDC...
  • Seite 36 CONNECTIVITY AND CABLE LENGTHS 1000W 550mm 150mm 150mm 150mm 150mm 4-pin 600mm 24-pin 20-pin 700mm 12V P4-connector 12V P8-connector 12V P4-connector 12V P8-connector 600mm PCIe (6+2-pin) PCIe (6+2-pin) PCIe (6+2-pin) PCIe (6+2-pin) PCIe (6+2-pin) PCIe (6+2-pin) S-ATA S-ATA 550mm S-ATA S-ATA S-ATA S-ATA...
  • Seite 37 850W / 750W 550mm 150mm 150mm 150mm 150mm 4-pin 600mm 24-pin 20-pin 700mm 12V P4-connector 12V P8-connector 12V P4-connector 12V P8-connector 600mm PCIe (6+2-pin) PCIe (6+2-pin) PCIe (6+2-pin) PCIe (6+2-pin) S-ATA S-ATA 550mm S-ATA S-ATA S-ATA S-ATA S-ATA S-ATA S-ATA S-ATA S-ATA...
  • Seite 38 650W 550mm 150mm 150mm 150mm 150mm 4-pin 600mm 24-pin 20-pin 700mm 12V P4-connector 12V P8-connector 12V P4-connector 600mm PCIe (6+2-pin) PCIe (6+2-pin) 600mm PCIe (6+2-pin) PCIe (6+2-pin) S-ATA S-ATA 550mm S-ATA S-ATA S-ATA S-ATA S-ATA S-ATA S-ATA...
  • Seite 39 550W 550mm 150mm 150mm 150mm 150mm 4-pin 600mm 24-pin 20-pin 700mm 12V P4-connector 12V P8-connector 12V P4-connector 600mm PCIe (6+2-pin) PCIe (6+2-pin) S-ATA S-ATA 550mm S-ATA S-ATA S-ATA S-ATA S-ATA S-ATA S-ATA 450W 550mm 150mm 150mm 150mm 150mm 4-pin 600mm 24-pin 20-pin 700mm...
