WIRING
ON
Indoor-monitor B, C and D are optional, depending on how many indoor units you intend to use.
Distance between units
1 - 50m
1 - 100m
8
1
1
2
2
1
1
Indoor Unit
2
B
2
1
Indoor Unit
2
C
1
Indoor Unit
2
D
Wiring
EN
USE
Intercom function:
unit, the indoor unit will chime. Press the intercom button to speak to the visitor.
Internal Intercom:
internal intercom function. Use this to communicate between your different indoor units.
Unlocking the door:
door.
Setting your ringtone:
Adjusting the ringtone volume:
Muting the ringtone:
be disturbed.
Power
Indoor Unit
Extension
When in standby, when a visitor presses the call button on the outdoor
When in standby, press and hold the intercom button to activate the
After identifying your visitor, you can press this button to unlock the
Press this button multiple times to set the melody of your choice.
Press this button to turn up the volume.
Press this button to mute the ringtone, for when you don't want to
EN
