Gewindestange vorne / Front Turnbuckle / bielle avant
125001000
125001000 4.8mm Ball End-Long
......12
125001010 3x40 Turnbuckle
............4
125001010 3x45 Turnbuckle
............2
L
R
23
L
Rear Hub Carrier
R
125001014 Rear bearing collar
...............2
125000910 1.6x11 Spring Pin
...............2
125000458 Ball stud-Long
............2
125000984 5x10x4 Ball Bearing
...............4
4mm
125001010
3x45
125001010
3x40
< R >
125000997
1.6x11
125001014
125000997
1:1 x1
3x45 Turnbuckle
1:1
x1
3x45 Turnbuckle
1:1
x2
3x40 Turnbuckle
1:1
x2
3x40 Turnbuckle
125000458
125000910
- 14 -
Front upper Rod-L
23.5mm
▲Projection.Note direction
Front upper Rod-R
23.5mm
▲Projection.Note direction
Steering Rod
18.5mm
▲Projection.Note direction
Rear upper Rod
17.5mm
▲Projection.Note direction
125001013
125000984
