Read the operating instructions and the enclosed brochure „Guarantee
!
and additional notices" completely. Follow the instructions they
contain. Safely keep these documents for future reference.
Function / Application
The Flexi3D-Camera is a micro camera which can be connected to the Video-
Control-Master base unit. Thanks to the small camera head and the twistable
cable base with angle scale, the Flexi3D-Camera is ideal for the inspection of
front and side areas. Working with a base unit, colour video images are sent
to the LCD for inspecting all places that are dif cult to access such as cavities,
air shafts, in masonry or motor vehicles.
1
2
5
1 Connection to the base unit
VideoControl-Master
2 Angle scale
3 Knob for locking
the camera head
06 GB
3
4
6
4 Wheel for adjusting the camera
5 Camera head with
4 high-power LEDs
6 Push rod
7 Control cable
7
