AR6310 User Guide
The AR6310 Nanolite 6-channel micro receiver is designed for micro, ultra light
foamie and parkflyer aircraft. Featuring DSM2
compatible with all Spektrum
DSMX technology, including: DX10t, DX8, DX7s, DX7SE, DX7, DX6i, DX5e, DX4e,
JR12X, JR11X , JRX9503, JRX9303, and Spektrum Module Systems.
NOTICE: The AR6310 receiver is not compatible with the Spektrum DX6 parkflyer
transmitter.
Features:
• 6-channel micro receiver
• Weight 2 grams
• Micro antenna
• JST servo connectors
• SmartSafe failsafe system
™
Applications
The AR6310 receiver is designed for Micro, Foamie and Slow Flyer aircraft only.
While the AR6310 receiver has more than adequate range for these types of
aircraft, it is imperative that it not be used in larger aircraft that could exceed its
operational range.

Specifications

Type: DSM2/DSMX Micro Parkflyer range
Channels: 6
Modulation: DSM2/DSMX
Dimension (WxLxH): 18.3 x 28.5 x 7.0mm
Weight: .07 oz (2 grams)
Input Voltage Range: 3.5–9.6V
Resolution: DSM2 1024, DSMX 2048
Compatibility: All DSM2/DSMX Aircraft Transmitters and Module Systems

Receiver Installation

The AR6310 Nanolite receiver is designed for micro light, foam and slow flyer
aircraft. Use double-sided foam tape to mount the receiver in place.
/DSMX
™
and JR /DSM aircraft radios that support DSM2/
™ ® ®
6
technology, the AR6310 is
®
