Activated charcoal filter (Recirculation version)
• The filter is not washable and cannot be regene-
rated. It must be replaced when led S1 flashes
or at least every 4 months. The alarm signal
will only light up when the extractor motor is
switched on.
Alarm signal reset
• Switch off the lights and extractor motor.
• Press T3 and hold for at least 3 seconds, until
LED flashes three times in confirmation.
Replacing the Filter
• Remove the grease filters.
• Remove the saturated activated charcoal filters
as shown (A).
• Fit new filters (B).
• Replace the grease filters.
Alarm signal activation
• In Recirculation Version Hoods, the Filter Saturation Alarm must be activated on installation or
at a later date.
• Turn the Lights and the Suction Motor off.
• Press button T2 and hold it for 5 seconds until the LED flashes twice in confirmation:
35 W halogen light.
• Remove the 2 screws fixing the light cover.
• Remove the lamp by gripping the protruding
part and turning to the left.
• Replace with a new lamp with the same cha-
racteristics, making sure that you insert the two
pins properly into their housings.
• Replace the cover and fix it in position using
the two screws removed as above
GB

REPLACING THE ACTIVATED CHARCOAL FILTER

Lighting

LIGHT REPLACEMENT

B
A
18
