USE

The hood can be switched on pushing directly onto the requested speed without firstly having to
select 0/1 button.
T1 T2 T3 T4
Button Led
-
L
Fixed
T1
Fixed
T2
Fixed
T3
Fixed
T4
Fixed
S1
Flashing
GB

Control Panel

S1
Function
Turns the lights on/off at maximum strength.
Turns the motor on/off at speed one.
Turns the Motor on at speed two.
Press and hold the button for approximately 3 seconds, with all the loads turned
off (Motor and Lights), to turn the Activated Charcoal Filter alarm on.
The relevant LED flashes twice to confirm.To turn the alarm off, press the
button again and hold for at least 3 seconds. The relevant LED flashes once.
Turns the Motor on at speed three.
Press and hold the button for approximately 3 seconds, with all the loads turned
off (Motor and Lights), to perform a reset of Filter saturation alarm. The LED
S1 flashes three times.
Turns the Motor on at INTENSIVE Speed.This speed is timed to run for 10
minutes. At the end of this time, the system returns automatically to the speed
that was set before.
If it is activated with the motor turned off, the hood will switch to OFF at the
end of the time.
Press and hold for 3 seconds to enable the remote control, indicated by the
LED flashing twice.
Press and hold for 3 seconds to disable the remote control, indicated by the
LED flashing just once.
Signals the Metal Grease Filter saturation alarm, indicating that it is necessary
to wash the filters. The alarm is triggered after the Hood has been in operation
for 100 working hours. (Reset see the parag. Maintenance)
When this is activated, it signals the Activated Charcoal Filter saturation alarm,
indicating that the filter must be changed; the Metal Grease Filters must also be
washed. The Activated Charcoal Filter saturation alarm comes into operation
after the Hood has been working for 200 hours. (Activation and Reset see the
parag. Maintenance)
L
T1
T2
T3
T4
S1
