Carson Nitrobone Automatic RTR Betriebsanleitung Seite 9

Charging jack
Charging Jack
Note: ON/OFF Switch should be at „OFF" position before
charging the batteries for the transmitter. Only Nickel-Cadmium
or Nickel-Metalhydride batteries (Ni-Cd/NiMH), such as
CARSON N o 50 005 4010 or its equivalents, are to be
recharged. If you attempt to recharge other types of batteries,
they may explode and cause injury or damage to you and
others.
DO NOT RECHARGE OTHER TYPES OF BATTERIES, SUCH AS
ALKALINE!
How to change transmitter batteries
• To remove the battery cover, push the cover lock and lift the
cover.
Warning: The batteries may fall out if the cover is removed. If
the transmitter voltage indicator LED fails to register, check the
contacts, especially the negative(-) terminals and recheck that
batteries are fitted correctly.
CARSON Automatic RTR: Nitrobone 50 010 3021 Stormracer 50 010 3022
Polung der Ladebuchse
Push and
lift here
Steering rate adjuster
Regler Lenkeinschlag
Increments of the Steering Servo Horn can be adjusted by
rotating this Steering Rate Adjuster, in the range from 10% to
100%.
The control can be rotated 300°. The range of movement is
greater whenever the control is turned to the right and smaller
whenever the control is turned to the left.
Also make sure the batteries are fully charged. Never mix
different battery types or batteries in different states of charge.
GB
9
