Chassis; Plug In Receiver Battery - Carson Nitrobone Automatic RTR Betriebsanleitung

Chassis

GB
Fuel-tank
Front tyre
Chassis
a. Plug in Receiver Batteries
Inset the onboard rechargeable battery supplied in the
compartment on the tail of the vehicle (see picture 1 + 2).
Connect the battery by the associated connector to the
onboard electronics.
Picture 1
10 CARSON Automatic RTR: Nitrobone 50 010 3021 Stormracer 50 010 3022
Air filter
Muffler
Front shock unit
Motor
Male and female connectors mate in one direction only. Finally,
close the battery compartment with the associated cover.
Picture 2
Rear shock unit
Rear tyre
Receiver box
Power switch
Throttle servo
Steering servo
