Technical Data; 24 V - Emergency Supply; Pictogram Explanation; Fire Recognation Element - D+H RZN 4503-T Originalbetriebsanleitung

Technical data

Type
Power supply
Rated power
Stand-by operating
Output voltage
Ripple
Output rated current
Number of lines / groups * 1 / 1
Fire detector per line
SHEV button per line
Current per group **
Mode of operation
- Monitoring
- Alarm / Ventilation
Housing
Colours
Ingress protection
Protection class
Temperature range
Dimensions WxHxD
VdS Approval-No.
* D+H Highspeed (HS) drives will be supported.
** The total current of the control panel must not be exceeded.

24 V - Emergency supply

Emergency power supply for 72 hours.
Use VdS approved storage batteries only!
1 x 12V / 3,4 Ah ±15 % (Type 8)
With connection of D+H alarm devices:
Total current of 3 A must not be exceeded. If
necessary, reduce drive current. Emergeny power
supply time of 72 hours can be shorter in case of
fire alarm. Total standby current (alarm devices
and +N) must not exceed 0.25 A.
Battery control - TD
T Temperature-guided charging of accumulator
D Discharge control
In case of power failure and total discharge of
accumulator, the control panel will switch off. In
this case, smoke vent is no longer ensured.
In this case a malfunction will be no more
indicated either.
99.825.18 2.4/03/18
RZN 4503-T
230 V AC, 50 Hz, +10%, -15%
100 VA
< 5 W
24 V DC
U < 0,5 V; < 1 %
ss
3 A
max. 14 pcs.
max. 8 pcs.
max. 3 A
Continuous duty
Short-time duty (30 % DC)
Aluminium
orange, gray, red, blue, yellow
IP 30
II with fuctional ground
-5 ... +40 °C
156 x 232 x 83 mm
G 509006 (only orange)
English

Pictogram explanation

SHEV alarm
Malfunction
Control panel O.K.
OK
D+H window drive
Mains existing
Vent button function "OPEN"
Smoke-/ vent button function "CLOSE"
Ground short

Fire recognation element

The control panel has an internal measuring device
for monitoring the internal temperature of the control
device. If the internal temperature is exceeding 72°C
(caused by radiant heat of a fire in immediate vicinity
of the mounting place), the entire smoke and heat
vent system will be emergency opened under alarm
conditions.
21/36
RZN 4503-T
