4) IR remote MODE:
The laser can be controlled by the IR remote control:
 Press the FUNC-button until the display shows: "REM".
 Press the ENTER-button to confirm your choice.
Note: In any standalone mode (excepted REM and SLA), press ON/OFF for 2 second to activate remote
function.
AUTO SHOW
MUSIC SHOW
LASER ON/OFF
COLOR
EFFECT PAUSE
CHANGING PATTERN
SOUND SENSIVITY
FIXED PATTERN (FROM 1 TO 48)
PATTERN REPEATING
Remote control details:
Button function
ON/OFF
In any other standalone mode except SLAVE: press 2s to
AUTO
Sound activated show, the blue is flashing when the
MUSIC
Sound sensivity In sound activated mode, press music+B+1to9 to change
COLOR
To change the color from red to green or red & green
CHANGING
PATTERN
CHANGING
FIXED
PATTERN
PATTERN
Last pattern and current pattern cycle repeating
REPEAT
5) DMX512 MODE:
The laser can be controlled by any standard DMX-controller in 2 different DMX-modes:
 1 CHANNEL MODE: for extremely easy setup and use! (display shows "1Ch")
 17 CHANNEL MODE: for full control of all possibilities. (display shows "17c")
 Connect the DMX input of the laser to the DMX output of the previous unit in the chain or directly to the
DMX-output of your controller.
 Press the FUNC-button until the display shows: "1C" or "17C".
JB SYSTEMS
®
USER MANUAL
Description
In REM mode: turn on/off the laser.
turn on the REM mode
Auto running show
sound is detected.
the sensitivity settings
To show and change patterns
You can select one pattern from 1 to 48
7/75 SMOOTH SCAN-3 LASER
ENGLISH
 Press the UP/DOWN buttons to select the DMX-mode. (1Ch or 17ch)
 Press the ENTER-button to confirm your choice.
 Press the FUNC-button: the 3 digit number on the display starts blinking.
 Select the DMX-address
 Press the ENTER-button to confirm your choice.
Note: the display blinks when the unit is in DMX-mode and no DMX-signal is detected.
Some more information on DMX512:
The DMX-protocol is a widely used high speed signal to control intelligent light equipment. You need to
"daisy chain" your DMX controller and all the connected light effects with a good
quality XLR M/F balanced cable. To prevent strange behavior of the light effects,
due to interferences, you must use a 90Ω to 120Ω terminator at the end of the chain.
Never use Y-splitter cables, this simply won't work!
Each effect in the chain needs to have its proper starting address so it knows which
commands from the controller it has to decode.
1 CHANNEL DMX-CONFIGURATION OF THE LASER:
DMX-
position value function
8 240-255 SOU
7 210-239 So2
6 180-209 So1
5 150-179 Aut
4 120-149 Au2
3 090-119 Au1
2 060-089 SOP
1 030-059 AUP
0 000-029 STANDBY
17 CHANNEL DMX-CONFIGURATION OF THE LASER:
IMPORTANT REMARK: DMX Channel1 is used to set the different working modes of the laser.
 To use the laser in full 17 channel mode, channel 1 must be set to value 221 or higher.
 Depending on the DMX-values of channel1, different mode can be applied:
DMX-
Channel value
000-020
021-040
041-060
061-080
CH1
081-100
Mode
101-120
121-140
141–160
161-180
JB SYSTEMS
®
USER MANUAL
remarks
Sound activated show with RGY
colors
Sound activated show with GREEN
color
Sound activated show with RED color
Automatic show with RGY colors
Automatic show with GREEN color
Automatic show with RED color
Sound activated pattern effect show
Auto running pattern effect show
Laser output off
function
Laser OFF
AUT
AU1
AU2
AU3
SOU
SO1
SO2
SO3
