Setting up and mounting
• The power strip can be screwed to a level surface.
• It can also be mounted or hung on a wall or cupboard using the holes at each end.
Ensure that the on/off switch is easily accessible and that it cannot be pressed by
accident.
• Follow the steps below to screw the power strip to a suitable surface:
• Place the power strip in the desired position. Use a spirit level to ensure that it is level.
• Mark the holes for two screws and then drill the holes. The type of screws and/or dowels
required may vary depending on the surface. These are not included and must be purchased
separately.
• Secure the power strip to the surface using screws and dowels, which should be placed into
the holes on each end.
• After inserting the screws, adjust the power strip to the desired position and tighten the
screws using a screwdriver. Do not overtighten the screws.
Operation
• Before using the power strip, unwind the mains cable and ensure that there are no loops.
Place the product in a suitable location. Ensure that nobody can trip over the cable. Use
suitable padding to protect furniture against scratches.
• Plug the power strip into a properly grounded mains socket (wall socket).
• Connect up to 8 appliances to the sockets on the socket strip.
• The sockets can be turned on/off using the on/off switch ("I" = on, "O" = off). The light in the
on/off switch illuminates when the sockets are turned on.
Maintenance and cleaning
• You do not need to carry out maintenance work on the product. Under no circumstances
should you service any of the components in the interior of the product, therefore never
open/dismantle it. Repair or maintenance work must only be carried out by a technician or a
specialist repair centre.
• Disconnect the product from the mains before cleaning and unplug all connected appliances.
• Never use aggressive detergents, rubbing alcohol or other chemical solutions, as these could
damage the casing or even impair the functioning of the product.
• Use a dry, lint-free cloth to clean the product.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product according to
the relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
Technical data
Operating voltage ......................... 230 – 250 V/AC,50/60 Hz
Total connected load ..................... Max. 3680 W (16 A)
Housing material ........................... Aluminium
Colour ........................................... Black
Child safety lock ........................... yes
On/off switch ................................. 2 poles (N/L), with integrated red control light
Cable type .................................... H05VV-F, 3G x 1.5 mm²
Cable length ................................. 1.8 m
Operating/storage conditions ........ -10 to +55 °C, 0 – 90 % relative humidity (non-condensing)
Dimensions (W x H x D) ............... 483 x 45 x 44.5 mm
Weight .......................................... 800 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2017 by Conrad Electronic SE.
*1517030_v4_0817_02_DS_m_3L_(1)
