INHALT Alle Betriebssysteme Systemanforderungen ....................................... USB Betriebsarten (USB Audio Klasse 1 & 2) ..............................Hinweise zur USB Audiowiedergabe USB Datenübertragungsverfahren ..................................Native Musikwiedergabe ..................................... Kernel Streaming ........................................ Installation und Einstellung Windows 7 und Windows 8 Installation ................................Windows 7 und Windows 8 Einstellungen ................................. Windows XP Installation ....................................
USB Schnittstelle weitere Installation benutzt werden. Der MP 3000 HV im USB Audio Klasse 1 Modus funktioniert im Microsoft Windows 10, 8.1, 8, 7 oder Windows XP mit den Normalfall auch an älteren Computern die nur über eine USB 1.1 jeweils aktuellsten Servicepacks Schnittstelle verfügen.
Daten vom Computer an und kann dadurch den Takt vorgeben. Durch diese Vertauschung der Rollen ist der Haupttakt des USB Gerätes (in diesem Fall der des MP 3000 HV) nun der maßgebende Takt. Dadurch sind jegliche durch den Computer verursachte Taktschwankungen ohne Bedeutung.
Methoden Da das PC-interne Handling der Audiodaten vom MP 3000 HV nicht unterstützt. beeinflusst werden kann, müssen auf dem PC geeignete Musikplayer mit entsprechenden Treibern und evtl. Plugins installiert werden, die Wird die J.River Media Center Software unter Windows 7 die Standard Audioverarbeitung des PC-Betriebssystems umgehen.
Windows 7 und Windows 8 Installation Bevor der MP 3000 HV an einen Computer im USB 2 Modus (High Speed Modus bis zu 192 kHz/24 Bit) angeschlossen wird, müssen als erstes die Gerätetreiber installiert werden! Gehen Sie dazu wie folgt vor: ...
Der MP 3000 HV sollte nur direkt an den Computer angeschlossen werden. Bitte benutzen Sie keine USB Verteiler (Hubs). Schalten Sie den MP 3000 HV ein und stellen Sie ggf. die USB- Betriebsart auf 'USB2' um (siehe Bedienungsanleitung S. 11/12).
Seite 11
Markieren Sie das 'T+A USB Audio Device' (SPDIF OUT) und klicken Sie anschließend auf 'Als Standard' klicken Sie auf 'Eigenschaften'. wählen Sie die Karteikarte 'Erweitert' durch Anklicken aus. hier können Sie die maximale Samplingfrequenz einstellen. Diese sollte im USB 1 Modus 96000 Hz / 24 Bit und im USB 2 Modus 192000 Hz / 24 Bit sein.
Windows XP Installation Bevor der MP 3000 HV an einen Computer im USB 2 Modus (High Speed Modus bis zu 192 kHz/24 Bit) angeschlossen wird, müssen als erstes die Gerätetreiber installiert werden! Gehen Sie dazu wie folgt vor: Laden Sie das Softwarepaket von der Homepage unter http://www.ta-hifi.com/mp3000hv-software...
Bitte benutzen Sie keine USB Verteiler (Hubs). Schalten Sie den MP 3000 HV ein und stellen Sie ggf. die USB- Betriebsart auf 'USB2' um (siehe Bedienungsanleitung S. 11/12). Der MP 3000 HV sollte nun von Windows automatisch erkannt werden.
Seite 15
Stellen Sie hier das 'T+A USB Audio Device' als Standardgerät ein.
MAC OS Installation ab 10.6.4 Bevor der MP 3000 HV an einen MAC Computer im USB 2 Modus (High Speed Modus bis zu 192 kHz/24 Bit) angeschlossen wird, müssen als erstes die Gerätetreiber installiert werden! Gehen Sie dazu wie folgt vor: ...
Seite 17
Um die Installation vollständig abzuschließen muss der Computer neugestartet werden, bestätigen Sie dies mit 'Restart'. Nachdem der Computer neugestartet hat, ist die Installation der Treibersoftware abgeschlossen. Im nächsten Kapitel werden die erforderlichen Systemeinstellungen beschrieben.
Der MP 3000 HV sollte nur direkt an den Computer angeschlossen werden. Bitte benutzen Sie keine USB Verteiler (Hubs). Schalten Sie den MP 3000 HV ein und stellen Sie ggf. die USB-Betriebsart auf 'USB2' um (siehe Bedienungsanleitung S. 11/12). Der MP 3000 HV sollte nun automatisch erkannt werden.
Seite 19
Markieren Sie als Audiogerät 'USB HS Audio-A2'. Wählen Sie unter Einstellungen 'Dieses Gerät für die Tonausgabe verwenden' Hier können Sie die maximale Samplingfrequenz einstellen. Diese sollte im USB 1 Modus 96000 Hz / 24 Bit und im USB 2 Modus 192000 Hz / 24 Bit sein.
Seite 21
CONTENTS All operating systems System requirements ....................................... USB operation modes (USB Audio Class 1 & 2) ............................... Notes on USB audio reproduction USB data transfer process ....................................Native music playback ...................................... Kernel Streaming ......................................Installation and settings Windows 7 and Windows 8 installation ................................Windows 7 and Windows 8 settings ..................................
96 kHz (24 Bit). When a USB device which System requirements is compatible with a Windows Driver Model - such as the MP 3000 HV - is connected, no drivers need to be installed, as they are an integral ...
This constitutes ‘role reversal’, i.e. the defining clock is now the main clock of the USB device - in this case the MP 3000 HV. The result is that any clock fluctuations generated by the computer have no effect at all.
Never connect or disconnect the USB connection while the system is running. This is the basic rule: in the final analysis the MP 3000 HV is only able The MP 3000 HV should never be switched off while to convert the audio data which is delivered by the PC and its playback.
Windows 7 and Windows 8 Installation The device drivers must be installed before you connect the MP 3000 HV to a computer using USB 2 mode (High-Speed mode: up to 192 kHz / 24 Bit). This is the procedure: ...
The MP 3000 HV should always be connected directly to the computer. Please do not use a USB distributor (hub). Switch the MP 3000 HV on, and if necessary change the USB mode to 'USB2' (see page 11/12 of the operating instructions).
Seite 29
Mark 'T+A USB Audio Device' (SPDIF OUT) and click on 'Set default' Click on 'Properties'. Select the 'Advanced' tab by clicking on it. At this point you can set the maximum sampling rate. This should be 96000 Hz / 24 Bit for USB 1 mode, and 192000 Hz / 24 Bit for USB 2 mode.
Windows XP Installation The device drivers must be installed before you connect the MP 3000 HV to a computer using USB 2 mode (High-Speed mode: up to 192 kHz / 24 Bit). This is the procedure: Download the software package from the website: http://www.ta-hifi.com/mp3000hv-software...
The MP 3000 HV should always be connected directly to the computer. Please do not use a USB distributor (hub). Switch the MP 3000 HV on, and if necessary change the USB mode to 'USB2' (see page 11/12 of the operating instructions).
Seite 33
Choose 'T+A USB Audio Device' as the default device...
MAC OS Installation (10.6.4 or higher) The device drivers must be installed before you connect the MP 3000 HV to a computer using USB 2 mode (High-Speed mode: up to 192 kHz / 24 Bit). This is the procedure: ...
Seite 35
The computer must now be restarted to complete the installation; confirm this with 'Restart'. Once the computer has restarted, the installation of the driver software is finished. The next section describes the system settings required.
MAC OS settings When installation is complete, you can connect the MP 3000 HV to your computer using any available USB port. The MP 3000 HV should always be connected directly to the computer. Please do not use a USB distributor (hub).
Seite 37
Now mark 'USB HS Audio – A2'. Check 'Use this device for sound output'. Format At this point you can set the maximum sampling rate. This should be 96000 Hz / 24 Bit for USB 1 mode, and 192000 Hz / 24 Bit for USB 2 mode.
Seite 38
