Stückliste Part List - Barbarian line BB-9035 Profi Half Rack Handbuch

Beachte: Einige der gelisteten Teile sind bereits vormontiert!
Note: Some of this parts may come pre-installed!
Item No.:
BB-9035 Profi Half Rack
Quantity Part-Name
1 2 9035(3)-1001
2 4 9035(3)-2000
3 1 9035(3)-2001
4 2 9035(3)-3001
5 1 9035(3)-4001
6 1 9035(3)-5001_L
7 1 9035(3)-5001_R
8 1 9035(3)-6001-L
9 1 9035(3)-6001-R
10 1 9035(3)-7001-L
11 1 9035(3)-7001-R
12 1 9035(3)-8001-R
13 1 9035(3)-8001-L
14 2 Aluminium Blind-Rivet Ø3,2mm
15 32 Auto-Lock-Nut M12
16 8 Button-Head-Screw M12x100
17 1 Identification-Plate
18 2 Label "BARBARIAN-LINE"
19 2 Numerary 1-23
20 2 Rectangular End-Cap 75x50mm
21 1 Reinforcementplate 100xØ14/65
22 6 Reinforcementplate 120xØ14/65
23 6 Rubber-Bumper_Ø30/Ø80x15
24 4 Rubber-Shoe for Tube 75x75
25 20 Screw M12x100mm
26 6 Screw M12x30
27 4 Screw M12x75mm
28 2 Square End-Cap 75x75mm
29 2 Strap-Rubber-Bumper, 350*25*10mm
30 8 Thread-forming countersink screw 4,2 x16mm
31 62 Washer M12
32 6 Weight_Horn Ø30x290mm
STÜCKLISTE
PART LIST
9
