• FROST - channel: 18 (Stnd) - 18 (16 b) - 20 (Extn)
• FOCUS - channel: 19 (Stnd) - 19 (16 b) - 21 (Extn)
• ZOOM - channel: 20 (Stnd) - 20 (16 b) - 22 (Extn)
ALPHA SPOT HPE 1200
BIT % EFFECT
189 - 255 74.0 - 100 HEAVY FROST
126 - 188 49.5 - 73.7 MEDIUM FROST
63 - 125 24.7 - 49.0 LIGHT FROST
WHITE
0 - 62 0.0 - 24.2
BIT % EFFECT
255 100 NEAR
0 0.0 DISTANT
BIT % EFFECT
255 100 NARROW BEAM
0 0.0 WIDE BEAM
• PAN - channel: 21 (Stnd) - 21 (16 b) - 23 (Extn)
Operation with option Pan Off
(Tilt conventionally represented at 15% and option Til
Operation with option Pan On
(Tilt conventionally represented at 15% and option Til
• TILT - channel: 22 (Stnd) - 22 (16 b) - 25 (Extn)
Operation with option Til Off
(Pan conventionally represented at 0% and option Pan
Operation with option Til On
(Pan conventionally represented at 0% and option Pan
32
Off)
BIT %
255 100
0 0.0
Off)
BIT %
255 100
0 0.0
Off)
BIT %
255 100
128 50.0
0 0.0
Off)
BIT %
255 100
128 50.0
0 0.0
