Water supply pressure
Maximum Load
Spin Speed

Installation

Unpacking

Warning!
• Read carefully the "Safety information" chapter
before installing the appliance.
x 3
A
B
x 3
x 1
C
x 2
W W arning! R R emove and k k eep all transit devices so
that they can be refitted if the appliance ever has
to be transported again.
Necessary tools
10 mm
30 mm
6 6
Minimum
Maximum
Cotton
Maximum
• Remove the external
film. Use a cutter, if
necessary.
0,05 MPa
0,8 MPa
7 kg
1400 rpm (ZWH7140AP)
1600 rpm (ZWH7160AP)
• Remove the cardboard top.
• Remove the polystyrene packaging materials.
1
2
• Remove the polystyrene base from the bottom.
• Spread the front piece
on the floor behind the
appliance and then lay
the appliance carefully
rear side down on it.
Make sure that no ho-
ses are crushed in the
process.
• Return appliance to it's
upright position.
• Open the door and re-
move the plastic hose
guide, the bag contain-
ing the instruction
booklet, the water inlet
hose and the plastic
plug caps from the
drum.
