STAND ALONE-MODE

In the Stand Alone mode, the LED ML-56 QCL RGBW/RGBA 18x8W can be used without controller.
Disconnect the LED ML-56 QCL RGBW/RGBA 18x8W from the controller.

Control Board

The Control Board offers several features: you can run the internal programs or set the
starting address.
Browse through the main menu by pressing MODE. You can change the selection by pressing
UP or DOWN. The functions provided are described in the following sections.
The display shuts off after 30 seconds of inactivity. With the touch of a button it lights up again.

Setting Solid Colors

Press the MODE button to select the solid color mode. When the display shows C, you can select the
desired solid color via the UP or DOWN buttons (see following graphic).
Mode:
C
Value:
C01
C02
C03
C04
C05
C06
C07
C08
C09
C10
C11
C12
C13
C14
C15
C16
C17
C18
C19
C20
C21
C22
C23
C24
C25
C26
C27
C28
C29
C30
Function:
RED
GREEN
BLUE
COLD WHITE
AMBER
SPRING YELLOW
CYAN
CYAN TONE 1
WARM WHITE TONE 1
PALE RED
PALE GREEN
MEDIUM BLUE
GREEN TONE 1
CYAN TONE 2
MEDIUM GREEN
WHITE FROST
STEEL BLUE
LIGHT BLUE
MEDIUM PINK
GREEN TONE 2
MEDIUM YELLOW
LIGHT GREEN
PINK
LIGHT PINK
BLUE MIST
MEDIUM WHITE
LIGHT CYAN
LILAC TINT
GREEN YELLOW
WARM WHITE TONE 2
