Congratulation with your new wood burning stove!
In order to get the best possible pleasure and benefit from your new Aduro wood burning stove, it is important that
you read this User Manual thoroughly before you install your wood burning stove and start to use it.
1.0 General
1.1 Compliance
Aduro 13 complies with the EN 13240 European standards, as well as the NS 3058 Norwegian standard and is
thereby approved for installation and use in Europe. At the same time, the manufacturing process is subject to
external quality control. Aduro 13 also carries the Nordic Swan Eco-label, which guarantees that the wood burning
stove complies with the most stringent environmental requirements and has been manufactured in an
environmentally correct manner. DoP (Declaration of Performance) can be seen on www.adurofire.com.

1.2 Technical data

Nominal power
Flue outlet, diameter
Measurements (HxBxD)
Height exhaust branch above floor level
Distance from centre of exhaust branch to
rear edge of fireplace
Weight
Material
Fuel
Max wood lenght
Convection stove
Primary-, secondary- and tertiary air supply
Air-wash system
Ashpan
Energy efficiency
Chimney draught
Maximum combustion amount per hour:
- Wood approx.
Heat rating in buildings with
- Optimum insulation
- Average insulation
- Inadequate insulation
1.3 IMPORTANT: PRODUCTION NUMBER
The fireplace insert has a production number at the bottom of the rating plate on the back of the fireplace. Besides
this the number is also stamped inside at the bottom of the door. We recommend that you note down this number
before mounting the fireplace insert. For the purposes of the guarantee and for other enquiries, it is important that
you are able to quote this number.
5 kW
Ø150 mm top/rear
870 x 480 x 345 mm
857 mm
160 mm
80 kg
Cast Iron
Wood and woodbriquettes
35 cm
80,5%
12 Pa
ca. 2,4 kg
2
150 m
2
100 m
2
60 m
P/ Nr.
20
English
