PROCESSOR

Internal controller:
A/D D/A converter:
Limiter:

USER INTERFACE

Presets ():
Controls:

I/O

Inputs:
Outputs:
USB:

POWER SUPPLY SPECIFICATIONS

Draw at 1/8 of full power in average
use conditions (*):
Draw at 1/3 of full power in
maximum use conditions (**):
Draw with speaker turned on without
signal (idle): :
Inrush current:
Total current and power allowed in
daisy-chain configuration:
* INSTALLER NOTES: The values refer to 1/8 of full power, in average operating conditions (music program with infrequent or no clipping). It
is recommended to consider them the minimum sizing values for any type of configuration.
** INSTALLER NOTES: The values refer to 1/3 of full power, in heavy operating conditions (music program with frequent clipping or activation
of the limiter). We recommend sizing according to these values in case of professional installations and tours.
LVX XM12
DSP 56 bit
28/56 bit/48 kHz
Peak, RMS, Termico
Wedge: [1] FLAT/ [2] VOCAL/ [3] HPF-80Hz/ [4] HPF-120Hz/
[5] Service
Speaker: [6] HF reduction/ [7] HF boost/ [8] loudness
Rotary BCD 8 Pos, MIC LINE SWITCH
COMBO XLR, 6.3 mm JACK
1x XLR link OUT
Type-B Mini-USB port
1,01 A / 110 W (230 V) - 1,71 A / 113 W (115 V)
1,89 A / 230 W (230 V) - 3,2 A / 230 W (115 V)
14 A - 3200 W max / 11 A - 1200 W max
19 W
27.3 A
Cod. 420120240 REV.1.0
