EuroLite TSL-200 Bedienungsanleitung Seite 26

Control-channel 3 - Color-wheel
Linear color change following the movement of the slider.
In this way you can stop the color-wheel in any position.
Decimal Hexad. Percentage S/F
0 15 00 0F 0% 6%
16 31 10 1F 6% 12%
32 47 20 2F 13% 18%
48 63 30 3F 19% 25%
64 79 40 4F 25% 31%
80 95 50 5F 31% 37%
96 111 60 6F 38% 44%
112 127 70 7F 44% 50%
128 255 80 FF 50% 100%
Control-channel 4 - Rotating gobo-wheel, gobo shake
Decimal Hexad. Percentage
0 7 00 07 0% 3%
8 15 08 0F 3% 6%
16 23 10 17 6% 9%
24 31 18 1F 9% 12%
32 39 20 27 13% 15%
40 47 28 2F 16% 18%
48 55 30 37 19% 22%
56 63 38 3F 22% 25%
64 71 40 47 25% 28%
72 79 48 4F 28% 31%
80 87 50 57 31% 34%
88 95 58 5F 35% 37%
96 103 60 67 38% 40%
104 111 68 6F 41% 44%
112 119 70 77 44% 47%
120 127 78 7F 47% 50%
128 255 80 FF 50% 100%
Control-channel 5 - Gobo rotation
Decimal Hexad. Percentage
0 15 00 0F 0% 6%
16 135 10 87 6% 53%
136 255 88 FF 53% 100%
Control-channel 6 - Shutter, strobe
Decimal Hexad. Percentage
0 7 00 07 0% 3%
8 15 08 0F 3% 6%
16 131 10 83 6% 51%
132 139 84 8B 52% 55%
140 180 8C B4 55% 71%
181 189 B5 BD 71% 74%
190 231 BE E7 75% 91%
232 239 E8 EF 91% 94%
240 247 F0 F7 94% 97%
248 255 F8 FF 97% 100%
S Open / white
S Dark blue
S Orange
S Yellow
S Pink
S Light blue
S Green
S Magenta
F Rainbow effect with increasing speed
S/F
S Open
S Gobo 1
S Gobo 2
S Gobo 3
S Gobo 4
S Gobo 5
S Gobo 6
S Gobo 7
F Open shake
F Gobo 1 shake
F Gobo 2 shake
F Gobo 3 shake
F Gobo 4 shake
F Gobo 5 shake
F Gobo 6 shake
F Gobo 7 shake
F Cont. gobo-wheel rotation with increasing speed
S/F
S No rotation
F Forwards gobo rotation with decreasing speed
F Backwards gobo rotation with increasing speed
S/F
S Blackout
S Shutter open
F Strobe-effect with increasing speed
S Shutter open
F Pulse closing with increasing speed
S Shutter open
F Pulse closing with decreasing speed
S Reset after 3-5 seconds
F Random strobe-effect
S Shutter open
26/28
Feature
Feature
Feature
Feature
00048760.DOC, Version 1.0
