SPECIFICATIONS
GENERAL
Channels ........................................................................................................................... 80 AM; 12FM
Frequency Range ................................................................................................ 26.565 to 27.405 MHz
Frequency Control ............................................................................................................................ PLL
Operating Temperature Range ...................................................................................... -10
DC input voltage ............................................................................................................ 13.8V DC
Size ............................................................................................................. 168 (L)x 49(H)x 164(P)mm
Weight .......................................................................................................................................... 1,0 Kg
RECEIVER
Receiving system .......................................................................... Dual conversion superheterodyne
Intermediate frequency ................................................................................................. I
.......................................................................................................................................... II
Sensitivity ..................................................................................... 0.5
.................................................................................................... 0.5
Audio output power @10% THD .................................................................................. 2.O W @ 8 Ohm
Audio distortion ................................................................................................. Less than 8% @ 1KHz
Image rejection .............................................................................................................................. 65dB
Adjacent channel rejection ............................................................................................................. 65dB
Signal/Noise ratio ........................................................................................................................... 45dB
Current drain at stand/by ............................................................................................................. 250mA
TRANSMITTER
Output power ............................................................................................. 4W FM 1W AM @ 13.8V DC
Modulation .......................................................................................................... AM: from 85% to 95%
............................................................................................................................. FM:1,8KHz
Frequency response .......................................................................................... from 400Hz to 2.5KHz
Output impedance ........................................................................................... RF 50 Ohm unbalanced
Signal/Noise Ratio .................................................................................................................40 dB MIN
Current drain1100mA ................................................................ (Power position with no modulation)
Approval:
The ALAN 120 ESP D80 possesses an approval from the Bundesamtes für Zulassungen in der
Telekommunikation. In Germany this model is liable for registration and charges.
All specifications are subject to change without notice.
°
bis +55
°
IF:10.695 MHz
°
IF:455 KHz
µ
V for 10 dB SINAD in FM mode
µ
V for 10 dB SINAD in AM mode
±
6
Frequencies:
Channel No.
1
2
°
C
3
±
15%
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
0,2KHz
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Frequency (MHz)
Channel No.
26.965
41
26.975
42
26.985
43
27.005
44
27.015
45
27.025
46
27.035
47
27.055
48
27.065
49
27.075
50
27.085
51
27.105
52
27.115
53
27.125
54
27.135
55
27.155
56
27.165
57
27.175
58
27.185
59
27.205
60
27.215
61
27.225
62
27.235
63
27.245
64
27.255
65
27.265
66
27.275
67
27.285
68
27.295
69
27.305
70
27.315
71
27.325
72
27.335
73
27.345
74
27.355
75
27.365
76
27.375
77
27.385
78
27.395
79
27.405
80
7
Frequency (MHz)
26.565
26.575
26.585
26.595
26.605
26.615
26.625
26.635
26.645
26.655
26.665
26.675
26.685
26.695
26.705
26.715
26.725
26.735
26.745
26.755
26.765
26.775
26.785
26.795
26.805
26.815
26.825
26.835
26.845
26.855
26.865
26.875
26.885
26.895
26.905
26.915
26.925
26.935
26.945
26.955
