Part Identifi Cation; Transmitter Battery Installation - iKarus mini Copter Bedienungsanleitung

Transmitter Transmitter
Power Power
Indicator Indicator Indicator
Throttle stick Throttle stick Throttle stick
Power Power
switch switch switch
Band
selector selector selector
Helicopter
Main rotor
Fuselage Fuselage
ON / OFF ON / OFF
switch
OFF
CHA CHA
ON
Charge socket
1.
1. Use a screwdriver to loosen the screws on the battery compartment by turning the
screw counter-clockwise.
2. Insert 6 AA size batteries into the battery compartment.
3. Close the battery cover, then tighten the screws by turning them clockwise.
Part Identifi cation
Direction stick
Trimmer
Charging indicator
Cover and
charging wire

Transmitter Battery Installation

2. 2.
Stabilizer
Main shaft
Main gear
Landing gear Landing gear
1 x Spare Tail Propeller Spare Tail Propeller
Tail rotor
3.
