EN
LOFT
Function settings

Continuous flow:

DIP switch 3
Enable the continuous flow function to fill the washbasin or a container.
'ON' position: Continuous flow function is enabled.
'OFF' position: Continuous flow function is disabled (default setting).
Enable continuous flow
Approach the infrared sensor
with your hand. The sensor
LED starts flashing. After
flashing three times, conti-
nuous flow is enabled for the
water arrest time configured.
22 Washbasin fitting
Enable continuous flow if
cleaning stop is enabled
(DIP 2 + 3 = ON)
Approach the infrared sensor
with your hand.
The water flow starts and
stops immediately after 5
flashes of the sensor LED.
After 3 further flashes the
waterflow starts and conti-
nuous flow is enabled.
3 x
WimTec LOFT
5 x + 3 x
ON
OFF
1 2 3 4 5 6
Disable continuous flow
Automatically after the water
arrest time set at DIP switch 5
(see page 18) has elapsed.
To instantly end continuous
flow, perform the same steps
as used for 'Enable
continuous flow'.
After flashing 3 times the
continuous flow is disabled.
3 x
