Phonemaster 100 05-04-2001
Phonemaster 100
1 INSTALLATION
To install the telephone, you have to do the following :
• Plug one end of the coil cord into the Phonemaster 100 and the other end into the handset.
• Plug one end of the telephone cable into the back of the unit "LINE" and the other end into the
telephone line wall socket.
Note : When the phone is in standby mode, nothing is shown on the display.
2 BUTTONS
1 Numerical buttons
2 Memory button
3 Set button
4 Redial button
5 Flash button
6 Direct Memory button M1
7 Direct Memory button M2
8 Direct Memory button M3
9 Direct Memory button M4
10 Direct Memory button M5
11 'Call' indicator (LED)
12 Volume switch
13 Flash time switch
14 Handsfree button
15 Ring volume switch
16 'In Use' indicator (LED)
17 Tone/Pulse switch
08:59 Page 12
12
2 6 7 8 9 10 3
17
13
11
16
15
1
12
4
14
5
