1. Installation ZMZ 0205 / ZMZ 0215
• Drill fixing holes in accordance with dimension drawing (Abb. 6)
• The coin meter can be mounted to the wall with the enclosed screws after opening
the device and dismounting the connecting covering cap.
• To secure the correct function of the coin meter, it is necessary to mount the coin
meter strictly vertical
Connection: Important! Before accessing the connection clamps, all power circles
has to be cut off.
VDE- and local regulations has to be attended
• On site, the connection has to be equiped with a switch of 3 mm break down.
• Carry the connection cords through cable sleeves
• For easy wiring the left part of connector is peelable. The terminal configuration is
printed on the terminal cover.
• Build up connection in accordance with wiring diagram (Abb. 1-5)
• While snap connector on keep secure latching in mind
• Refit terminal cover
Safety low-tension (Option „L")
While usage in humid areas the connection with a 24 V safety low-tension is suggested.
Therefore you have to install a 24 V AC cord into the humid area. A 230 V / 24 V 100 VA
power transformator for up to 4 ZMZ controls is available ex factory.
2. Short manual ZMZ 0205
2.1 Settings
The ZMZ 0205 is equiped with a 1-digit LED to display the number of inserted coins or
remaining time. Up to two coins can be insered into the device at once.
Additional coins do not lengthen the remaining time.
Afreshing of time can only occur after the termination of time. Time base can be swit-
ched from HH:MM to MM:SS.
Delivery status
Jumper 1 open
only one coin will be accepted
Jumper 2 open
Upper Dip for setting of minutes
Lower Dip for setting of hours
