OPERATION

1.
2. Signal input selection [see designations; numbers 6, 30, 37]
3. Gain [see designations; numbers 1 & 4]
4. Equalizer [see designations; numbers 2 & 5]
5. Channels A + B [see designations; numbers 17 & 42]
6. Crossfader [see designations; numbers 21 & 41]
26
Power on [see designations; number 27]
After having connected all necessary devices turn on the mixer via the
ON/OFF switch -27-.
With the signal input selectors for channels A + B -6- you can choose
between line, phono, CD, AUX and USB sources (only available for the Reloop
IQ2+ USB); (for channel A you have the additional AUX position as described
in the chapter "connections", number 5). Please follow the labeling of the
signal input selector for channels A + B -6- and also the phono/line switch
position for channels A + B -30-.
The input volume for channels A + B can be adjusted via the gain knobs for
channels A + B -4-. With the microphone gain knob -1- you can adjust the
input volume of your DJ microphone channel.
It is possible to adjust the low, mid and high frequencies via the 3-band
equalizer for channels A + B -5-. With the 2-band equalizer for the
microphone -2- you can adjust the low and high frequencies for the DJ
microphone channel.
Via the linefaders -17- you can adjust the output volume for channels A + B.
The linefader curve can be adjusted via the linefader curve switch -43- and
the linefader curve knob -42-. There are three different positions for the
linefader curve switch. If the switch is in the outer left position you will be
able to hear the signal with the linefader being in a fairly low position; the
linefader is "hard" (highly appropriate for cutting and scratching). If the
switch is in the middle position you will obtain a linear curve, this means the
linefader is "smooth" (great for long running mixes); the signal rises
proportionally to the linefader's position. When the switch is In the outer
right position the linefader becomes "hard", similar to the left position. The
signal only becomes audible when the linefader is in a rather high position
(also highly appropriate for cutting and scratching).
Furthermore it is possible to obtain a vernier adjustment of the fader curve
by using the linefader curve knob -42- in order to work even more precisely.
By turning the knob clockwise the fader curve becomes "hard"; by turning
the knob counter clockwise the fader curve becomes "smooth".
With the crossfader -21- you can switch between the left and right crossfader
channel. The crossfader curve can be adjusted via the crossfader curve
switch -41-. When the switch is in the left or middle position the crossfader
curve becomes "hard" (highly appropriate for cutting and scratching); when
the switch is in the right position the crossfader curve becomes "smooth"
(highly appropriate for long running mixes).
