Check the connections

Figure 7
Completed con-
nections
10
Downloaded from www.Manualslib.com
Setting Up
Make sure each connection is made positive to positive (+ to +)
and negative to negative (– to –). Check to be sure that no loose
strands of wire touch across terminals. Bridged wires can short-
circuit and damage the electrical components. Tighten any loose
connections before you plug in the receiver or amplifier and turn it
on.
Center speaker
Receiver or
amplifier
Right Surround speaker
manuals search engine
A
B
Left Surround speaker
OUTPUT
To speakers
FRONT SURROUND CENTER
SPEAKERS SPEAKERS SPEAKER
Left
Right Right Left
+ – + –
+ +
A
B
– –
+ – + –
Right Left
