Variante E3; Variante E2 - IPC IPC191V3 Betriebsanleitung

3.5 Variante E3

Assembly
Mainboard
Ethernet
Adapter 1X

3.6 Variante E2

Assembly
Mainboard
Ethernet
Adapter 2X
Änderungen vorbehalten
IPCOMM GmbH
Gundstraße 15
D-91056 Erlangen
Linux
Device I/O port
ttyS0 3F8
ttyS1 2F8
ttyS2 3E8
eth0 PCI (Onboard) Auto LAN1
eth1 PCI (Onboard) Auto LAN2
eth2 PCI (Onboard) Auto LAN3
eth3 PCI (Onboard) Auto LAN4
eth4 PCI (Slot 2)
Linux
Device I/O port
ttyS0 3F8
ttyS1 2F8
ttyS2 3E8
eth0 PCI (Onboard) Auto LAN1
eth1 PCI (Onboard) Auto LAN2
eth2 PCI (Onboard) Auto LAN3
eth3 PCI (Onboard) Auto LAN4
eth4 PCI (Slot 1)
eth5 PCI (Slot 1)
- 13 -
IRQ Label
COM1 (Chassis
4 rear)
COM2 (Chassis
3 front)
5 CPU (Diagnose)
Auto LAN5
IRQ Label
COM1 (Chassis
4 rear)
COM2 (Chassis
3 front)
5 CPU (Diagnose)
Auto LAN5
Auto LAN6
Copyright © 2014 IPCOMM GmbH
Alle Rechte vorbehalten
Connector
DB9ST
DB9ST
NOT Connected
RJ45
RJ45
RJ45
RJ45
RJ45
Connector
DB9ST
DB9ST
NOT Connected
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
Version 2.5
IPC191V3 Anleitung
