Handheld transmitter
Model name:
Modulation:
Frequency range:
Channels:
Groups:
Microphone type:
Polar pattern:
Frequency response:
THD:
Signal-to-noise ratio:
RF output power:
Controls:
Indicators:
Power supply:
Operating time:
Operating temperature range:
Relative humidity range in operation:
Dimensions (L x Ø):
Weight (without batteries):
Accessories included:
Features:

Bodypack transmitter

Model name:
Modulation:
Frequency range:
Channels:
Groups:
Input:
Frequency response:
THD:
Signal-to-noise ratio:
RF output power:
Controls:
Indicators:
Power supply:
Operating time:
Operating temperature range:
Relative humidity range in operation:
Dimensions (W x H x D):
Weight (without batteries):
Accessories included:
Features:
LDU50xMD
FM
823 - 832 MHz & 863 - 865 MHz (LDU508), 584 - 607 MHz (LDU505), 655 - 679 MHz (LDU506),
604 - 614 MHz (LDU506UK)
96 (8 x 12)
8
dynamic
cardioid
60 - 16.000 Hz
<0.2% @ 1kHz
>95 dB
2mW, 10mW, 30mW switchable and depending on the RF -Range
Power on/off, Select, Arrow button
multifunctional OLED-graphic display
2 x AA battery
up to 10 h (depending on batteries)
5°C ... 40°C
20% ... 80% (non condensing)
257 x 51mm
0,2 kg
2 x AA battery
infrared frequency synchronisation
LDU50xBP
FM
823 - 832 MHz & 863 - 865 MHz (LDU508), 584 - 607 MHz (LDU505), 655 - 679 MHz (LDU506),
604 - 614 MHz (LDU506UK)
96 (8 x 12)
8
3-pin mini-XLR (Low-Z/High-Z)
30 - 16.000 Hz
<0.1% @ 1kHz
>90 dB
2mW, 10mW, 30mW switchable and depending on the RF -Range
Power on/off, Select, Arrow button
multifunctional OLED-graphic display
2 x AA batteries
up to 10 h (depending on batteries)
5°C ... 40°C
20% ... 80% (non condensing)
65 x 86 x 23 mm
0,09 kg
2 x AA battery
infrared frequency synchronisation
LDU50xMC
condenser
cardioid
257 x 50mm
0,21kg
15
